Original huawei e5776 huawei LTE router huawei e5776 4g lte router

Huawei E5776 4G LTE Mobile WiFi Hotspot is the world's first LTE Cat4 LTE MiFi, which support data rates of 150Mbps downstream and 50Mbps upload speed. Up to 10 WiFi devices could access internet via WiFi. The 1.45 inch wide screen displays all relevant data such as battery level, volume consumed and network availability. There are many branch modelfor this Cat4 LTE Hotspot, such as HUAWEI E5776s-860, HUAWEI E5776s-32, HUAWEI E5776s-22, HUAWEI E5776s-501, HUAWEI E5776S-420, HUAWIE E5776s-922, HUAWEI E5776s-601 etc..

On UMTS network, it supports up to 84mbps download speed via DC-HSPA+. As the successor of HUAWEI E589 4G LTE Pocket WiFi, it's LTE-advanced model.

Product Specs
1, WLAN: IEEE 802.11b/g/n

2,  LTE B1 B3 B7 B8 B20 (FDD-800/900/1800/2100/2600Mhz)

3, LTE (DL) data service of up to 150 Mbit/s(FDD)
4, LTE (UL) data service of up to 50 Mbit/s(FDD)
5, LTE (DL) data service of up to 112 Mbit/s (TDD)
6, LTE (UL) data service of up to 10 Mbit/s(TDD)

7, 4G/3G: DC-HSPA+/HSPA+/HSPA/UMTS 2100/900Mhz

8, 2G: EDGE/GPRS/GSM   850/900/1800/1900Mhz

9, LTE speed up to 150Mbps

10, DC-HSPA+ data service of up to 42 Mbps

11, HSUPA data service of up to 5.76 Mbps

12, micro SD Card Slot (up to 32GB)

13, Equalizer and receive diversity

14, Data and SMS Service

15, Wi-Fi and WPS

16, Built-in DHCP Server, DNS RELAY and NAT

17, Five-second fast boot
18, Depending on the state of network and environment

System requirements

Windows XP, Windows Vista, Windows 7, MAC OS X 10.5, 10.6 and 10.7

Below are the 4G, 3G and 2G Frequency band that the brach model could support:

HUAWEI E5776s-860:

* LTE-TDD 2300/2600MHz

* LTE-FDD 2600MHz

* TD-SCDMA/WCDMA

* GSM/GPRS/EDGE

Huawei E5776s-601

* 4G LTE-TDD 2300MHz

* 4G LTE-FDD 1800/2600MH

* 3G WCDMA 900/2100mhz

* 2G GSM/GPRS/EDGE 900/1800 MHz

Huawei E5776s-922

* 4G LTE-TDD 2300/2600MHz

* 4G LTE-FDD 1800/2600MHz

* 3G TD-SCDMA/WCDMA 900/2100mhz

HUAWEI E5776s-32:

* LTE FDD 800/900/1800/2100/2600MH

* UMTS 850/900/1900/2100MHz

* GSM 850/900/1800/1900MHz

HUAWEI E5776s-22:

* LTE-TDD 2600 MHz
* LTE-FDD 800/1800/2600 MHz
* UMTS 900/2100 MHz
* GSM 900/1800 MHz
