CE Certificate CNC Router for Wood Furniture 1224 1325 1530 2030

                            CE certificate  CNC Router for Wood Furniture 1224 1325 1530 2030

1 .Product description

Features:

 a.1325-type engraving machine is a classic engraving machine, equipped with all the high-quality components.

b.using Shuntong 3kw spindle (water), frequency 3.7kw, Weihong system

c. table for leading international high strength, vacuum adsorption countertops, high adsorption power can be strong adsorption of materials of different sizes

d. intelligent protection work table tops, to prevent misuse of goods software errors may cause damage; intelligent processing cross-border protection,

e. prevent over processing format layout design of mechanical collision caused the phenomenon.

f. Weihong system, auto-complete multi-level 3D processing, can be fast, smooth three-dimensional machining, engraving or cutting.

 g.overall steel welding tempering aging treatment, solid shape, Gantry mobile, fixed working table can be arbitrary processing surface material.

2 . Technical Parameters:

project
Performance
parameter

Optional
stroke
X stroke
1300mm<2500mm
Y travel

2500mm<5500mm
Z stroke
120mm<450mm
Platform size

1440x2915mm

Accuracy
Precision
0.04mm

Repeatability
0.05mm

structure
Mesa structure
Vacuum
Submit adsorption
XYZ structure
X, Y rack, Z screw

speed
The maximum speed of blank lines
2000 / min

Maximum operating speed
1500mm / min

Spindle
Spindle power
3.0KW
8.0 Spindle
Run mode

Stepping

Operating Voltage

AC380v / 50Hz
AC380v / 60Hz
Run command

G code

operating system

Weihong system

net weight

1600kg

GW

1900kg

Sample :
