Digital High-accuracy Underground Metal Searching GPR System, Ground Prospecting Radar

Typical Application:

Utility location
Tunnel lining detection & advanced prediction
Road quality inspection
Mining, Geology, Hydrological survey
Rebar & Cable detection
Dam inspection
Life detection
Geotechnical engineering
Concrete inspection
Archeology

Main Featrures:

The integrated design of host and antenna
Easy to use, no field installation
High reliability wireless communication
Easy-to-use interface，one-click parameter setting, perfect or the field operation

Main Specification:

Center frequency: 100M 200M 400M 600M 1GHz 1.6GHz
Pulse repeated frequency: 50kHz~250kHz
Time range: 0-800ns
Number of samples: 512-8192 samples/scan, user selectable
Scan rate: 1-480 scan/sec
Operating modes: Point mode, survey wheel, free run
Display modes: Pseudo color，stacked waveform or grey-scale
Operating temperature: -10℃-+70℃
Battery: Li-Ion (12V 10AH)
Wireless Communication: 802.11b/g/n,>25 m
Wired communication: RJ45 100BT Ethernet

Packing Detailes:

The product will be packed by customized wooden case, detailed dimension and weight information will be provided after packing.
