Product Details
| Place of Origin | China | Brand Name | HI-TARGET | |
| Model Number | V60 GNSS RTK System |
Product Description
GPS Receiver Type GPS Module with 220 Channels for Engineering Construction
The V60 is a more compact-design and higher-performance GNSS RTK system, besides its rugged design to resist impact and vibration. The V60 has industrial OLED display screen on its front control panel to show all information and status of the work. With the smart speaker inside the receiver, the DIY guiding voice can be customized in any language, even dialect! 1GB internal storage plus 8GB Micro SD card memory is standard, the V60 supports up to 32GB extension of memory. The V60 is fully compatible with other GNSS RTK receivers from the world market. The static data can be saved directly in RINEX format.
Main specification of the V60 GNSS RTK GPS receiver:
| Measurements | • 220 Channels |
| • Advanced Pacific Crest Maxwell 6 Custom Survey GNSS Technology | |
| • High precision multiple correlator for GNSS pseudo range measurements | |
• Unfiltered, unsmoothed pseudo range measurements data for low noise, low multipath error, low time domain correlation and high dynamic response | |
• Very low noise GNSS carrier phase measurements with <1 mm precision in a 1 Hz bandwidth | |
| • Signal-to-Noise ratios reported in dB-Hz | |
| • Proven Pacific Crest low elevation tracking technology | |
Satellite signals tracked simultaneously | GPS: Simultaneous L1C/A, L2C, L2E, L5 |
| GLONASS: Simultaneous L1C/A, L1P, L2C/A (GLONASS M only), L2P | |
| SBAS: Simultaneous L1 C/A, L5 | |
| Galileo: Simultaneous L1 BOC, E5A, E5B, E5AltBOC | |
| BDS/Compass: B1, B2 | |
| QZSS: L1 C/A, L1 SAIF, L2C, L5 | |
| POSITIONING PERFORMANCE | |
Static and Fast Static GNSS surveying | Horizontal: 2.5mm+0.5ppm RMS |
| Vertical: 5mm+0.5ppm RMS | |
| Post Processing Kinematic | |
| (PPK / Stop & Go) GNSS surveying | Horizontal: 1cm+1ppm RMS |
| Vertical: 2.5cm+1ppm RMS | |
| Initialization time: typically 10 minutes for base while 5 minutes for rover | |
| Initialization reliability: typically > 99.9% | |
| Real time Kinematic (RTK) surveying | Horizontal: 8mm+1ppm RMS |
| Vertical: 15mm+1ppm RMS | |
| Initialization time: typically < 8 seconds | |
| Initialization reliability: typically > 99.9% | |
| Code Differential GNSS positioning | Horizontal: 25cm+1ppm RMS |
| Vertical: 50cm+1ppm RMS | |
| SBAS: 0.50m Horizontal, 0.85m Vertical | |
| HARDWARE | |
| Physical | Dimensions (W x H): 18.20cm x 9.80cm (7.17 in x 3.86 in) |
| Weight: 1.25kg (2.76lb) without internal battery | |
| Operating temperature: -45℃ to +65℃ (-49℉ to +149℉) | |
| Storage temperature: -55℃ to +85℃ (-67℉ to +185℉) | |
| Humidity: 100%, considering | |
Water/dustproof: IP67 dustproof, protected from temporary immersion to depth of 1m (3.28ft) | |
Shock and Vibration: Designed to survive a 3m (9.84ft) natural fall onto concrete | |
| Electrical | Power 6V to 28V DC external power input |
| Power consumption ≤3.5W | |
| Automatic Switching between internal power and external power | |
| Rechargeable, removable 7.4V, 5000mAh Lithium-Ion battery in internal battery compartment | |
| Internal battery life | Static 13 - 15 hours |
| RTK Rover (UHF/GPRS/3G) 10 - 12 hours | |
| RTK Base 8 - 10 hours | |
| I/O interface | 1 x Bluetooth |
| 1 x standard USB2.0 port | |
| 1 x TNC UHF connector | |
| 2 x RS232 serial port | |
| 2 x DC power input (8-pin & 5-pin) | |
| 1 x Micro SD card port | |
COMMUNICATION & DATA STORAGE | |
| 3G Communication | Fully integrated, fully sealed internal 3G, compatible with GPRS |
| Network RTK (via CORS) range 20-50km | |
| HI-TARGET internal UHF radio (standard) | Frequency: 450~470MHz with 116 channels |
| Transmitting Power: 1W, 2W, 5W adjustable | |
| Transmitting Speed: 9.6Kbps, 19.2Kbps | |
| Working Range: 5km typical, 8~10km optimal | |
| Pacific Crest internal UHF radio | Frequency: 403~473 MHz |
| Transmitting Power: 0.5W, 2W adjustable | |
| Transmitting Speed: Up to 19.2Kbps | |
| Support most of radio communication protocol | |
| Working Range: 3~5km typical, 8~10km optimal | |
| HI-TARGET External UHF radio (standard) | Frequency: 460 MHz with 116 channels |
| Transmitting Power: 5W, 10W, 20W, 30W adjustable | |
| Transmitting Speed: Up to 19.2Kbps | |
| Working Range: 8~10km typical, 15~20km optimal | |
Pacific Crest ADL Vantage Pro External UHF radio | Frequency: 390~430 MHz or 430~470 MHz |
| Transmitting Power: 4W to 35W adjustable | |
| Transmitting Speed: Up to 19.2Kbps | |
| Support most of radio communication protocol | |
| Working Range: 8~10km typical, 15~20km optimal | |
Support other external communication device | For example, external GSM modem |
| Data storage | 1GB Internal storage+ 8GB Internal Micro SD Card memory (Support up to 32GB extension) |
| Record GNS and Rinex format simultaneously | |
Applications of the engineering construction land survey GPS receiver:
