Belt Vulcanizing Press

Specifications

    Belt Vulcanizing Press--vulcanizing machine and tools for repairing & splicing all kinds of conveyor belt, such as EP, rubber, Nylon,canvas, fabric, ST.

    Belt Vulcanizing Press  made of high strength aluminum alloy, small size, light weight, easy handling and installation, electric heating plate face temperature distribution is uniform, manual / automatic body control hydraulic pressure equipment for the plate structure has the advantages of pressure and uniform. The kinds of products is the vulcanization bonding of advanced equipment.

   It can be widely used in various curing tape under the condition of joints and complement access work (plus regular canvas belt. High-strength nylon tape. Rope core tape, etc.)

Main Technical Parameter
1. Vulcanization pressure: ≤1.5Mpa;
2. Vulcanization temperature: 145 °C;
3. Difference in surface temperature of vulcanized plate: ± 3 °C;
4. Calefactive time (at normal temperature to 145 °C): ≤30 mins;
5. Power supply voltage: 220V to 660 v;  50/60 Hz; 3Ph;
6. Output power of Electronic Control Box: 36 KW;
7. Temperature adjustment range: 0 to 200 °C;
8. Timing adjustment range: 0 to 99 min;
9. After the pressurization of 0.8 MPa, the gap between upper and lower heating plate is not more than 0.4 mm.
