Aluminum Foil Fireproof Foam Insulation for Construction
- Ho Chi Minh City
- T/T
You May Like
-
Fireproof Foil Bubble Insulation PE Foam Soundproof Sunshade Reflective Double-sided Roll Wrap
-
Aluminum Single Bubble Foil Insulation
-
Reflective Bubble Insulation for Thermal Insulated Pallet Covers
-
Aluminum Bubble Insulation for Packing and Wrapping Temprature Sensitive Cargo
-
Metalized Bubble Insulation for Packing and Wrapping Cargo
-
Pallet Cover for Air Conditioner, Aluminum Bubble Foil for Packing Wrapping and Transportation
Product Details
| Place of Origin | Ho Chi Minh City, Vietnam | Brand Name | Cat Tuong | |
| Model Number | A2 Double |
Product Description
Specifications
Heat insulation made of two external pure aluminum foil layers covering a double core layer of polyethylene bubble air.A2 Cat Tuong Double Material is composed of 2 layers of bubbles air made from polyethylene sandwiched between two layers of aluminum. The aluminum foils are heat reflective and the bubbles air are heat and sound insulation.
It keeps buildings warm in winter and cool in summer.
It is strong, light weight, clean and does not degrade over time.
It is easy and fast to install- usually save up to 50% labor time.
It prevents about 90% of heat radiation, decreases the temperature by 12-22C inside compared to the metal roof.
It can be installed under the roof, between the walls, under the ceiling and the floor.
It is environmental friendly, energy saving, fire retardant and has no odor or toxicity.
It replaces the glass wool or rock wool which after a few years degrade, became dusty and unhealthy.
It is largely used in industrial and civil construction, warehouse, livestock…in Vietnam, Thailand, China, Malaysia, Philippine, Indonesia, Australia, New Zeeland, United States…
It can also be used in other application that needs shock protection such as bag in transport with container…
Thermal reflective insulation made of two external pure aluminum foil layers covering a single core layer of polyethylene bubble air film. (Product is manufactured by USA standard).
Structure: Aluminum foil/ Bubble Air Bag/ Bubble Air Bag/ Aluminum foil.
Property | Standard | Unit | Value |
Sheet structure | Aluminum foil/ Bubble air /Bubble air / Aluminum foil | ||
Roll Size |
| m x m | 1.55 x 30 |
Sheet thickness |
| mm | 6(± 0.5) |
Roll weight |
| kg | 24 (±0.3) |
Yield strength |
| g/m2 | 320 |
Reflectivity | ASTM C1371 | % | 99.96 |
Emissivity | ASTM C1371 | € | 0.04 |
Classification of Surface Spread of Flame (Aluminum surface) | BS-476 .Part 7 |
| Class 1 |
Elongation | ASTM D638 | % | 13.49 |
Tensile strength | ASTM D638 | N/mm2 | 1.1 |
Tear strength | ASTM D1004 | kN/m | 16.24 |
Bursting strength | ISO 13938-2-99 |
| 120.8 |
Water absorption | ASTM E960 | g/ft2 hr | 0.19 |
Resistant to mold and bacteria |
|
| Yes |
Toxicity |
|
| No |
