HGY-650 core sample drilling machine for geological prospecting
USD $1 - $2
/ Set
1 Set(Min.Order)
- 40 Set / Sets per Month
- Shenzhen/Shanghai/Guangzhou
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Other, Core Drilling Rig, Drilling Rig | |
| Power Type | Diesel | Place of Origin | Hunan, China | |
| Brand Name | FLYDISC | Model Number | HGY-650 | |
| Usage | Ore | Voltage | 220V | |
| Power(W) | 15KW | Dimension(L*W*H) | 1860*800*1400CM | |
| Weight | 750KGS | Certification | ISO9001:2008, CE certificate | |
| Warranty | half a year | After-sales Service Provided | Overseas service center available |
Product Description
HGY-650 core sample drilling machine for soil/rock survey
Brief introduction of Company:
1.50 years professional manufacture
2. Certificate: ISO9001:2000 and ISO9001:2008
3. Export to: Africa, the Middle East, South America, Asia,
Countries: South Africa, Zambia, Sudan, Iran, South Korea, Costa Rica etc.
Drilling Ability of HGY-650 core sample drilling machine
Drilling depth: 650m
Drill hole diameter: 75mm(46~250mm)
Features of HGY-650 core sample drilling machine :
1) Compact in structure and light in weight.
2) High reliability, good performance and durability.
3) Common auto parts, such as clutch, transmission case and shifting structure.
4) Safe and reliable operations with synchronizer for shifting while the rig is running.
5) Be attached to the tower.
Use of HGY-650 core sample drilling machine :
1.Construction drilling of the projects e.g. prospection, railway, road, port, bridge, water conservancy and hydropower, tunnel, well, industrial and civil construction
2. Coal mining exploration, Ore exploration
3. Small hole diameter water well drilling
4. Geothermal pipe-installing for heat pump
5. Small-diameter hole foundation piling drilling;
Technological Data of HGY-650 core sample drilling machine :
Model | HGY-650 Drilling Rig |
Drilling depth( m) | 650 |
Spindle speed( r/min) | Positive rotation rate: 65 117 201 309 440 187 338 582 894 1273 Reverse rotation rate: 72 207 |
Spindle stroke(mm) | 600 |
Lifting power max( KN) | 80 |
Driving force max(KN) | 60 |
Spindle output torque max(N.M) | 3435 |
Spindle hole diameter( mm) | Φ65 |
Lifting speed( m/s) | 0.43 0.78 1.35 2.08 2.95 |
Lifting capacity(single) max(KN) | 33 |
Diameter & Length of drum(m) | Φ15*90 |
Movable cylinder stroke (mm) | 400(+-10) |
Max distance from hole (mm) | 250 |
Gear oil pump model | CB-F32C-FL |
Nominal displacement( ml/r) | 32 |
Nominal pressure( MPa) | 16 |
Oil pump nominal rotation velocity(r/min) | 1800 |
Electromotor model | YB200L-4 |
Power( kw) | 26 |
Diesel engine model | 4100K |
Power( kw) | 36 |
Speed( r/min) | 1800 |
Weight(power unit excepted)(Kg) | 1550 |
Overall dimensions(mm) | 2400*1020*1700 |
