Home > Products > Others > Dinghua DH-A08 BGA rework station repair system for soldering and desoldering chips
Dinghua DH-A08 BGA rework station repair system for soldering and desoldering chips
- Shenzhen
- T/T Credit Card PayPal
You May Like
-
DH- A09L Pcb solder system for laptop tablet PC mobile repair bga rework system
-
Dinghua DH- A09L Notebook Computer motherboard repair machine rework equipment BGA rework system
-
Dinghua the lowest cost DH-A01 smd rework equipment repairing chipsets IC
-
DINGHUA DH-A01R infrared bga rework station for computer/ mobile phone/ game console motherboard bga chip repair
Quality Choice
-
DINGHUA DH-A01R infrared bga chip replace tool
-
Dinghua DH-A01 laptop/mobile repair machine digital panel meter bga rework station bga rework equipment
Product Details
| Place of Origin | Guangdong, China | Brand Name | DINGHUA | |
| Model Number | DH-A08 | Voltage | AC220V±10% 50/60Hz | |
| Current | 35A | Rated Capacity | 4800W | |
| Rated Duty Cycle | 100% | Dimensions | 570*600*600mm | |
| Weight | Net weight 30kg | Usage | desolder/solder chips of guided missles, integrated motherboardfs etc. | |
| Certification | CE ISO 9001 20008 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Dinghua DH-A08 BGA rework station repair system for soldering and desoldering chips
Specifications:
Power | 4800W |
Top heater | Hot air 800W |
Bottom heater | Hot air 1200W, Infrared 2700W |
Power supply | AC220V±10% 50/60Hz |
Dimension | L570*W600*H600mm |
Positioning | V-groove, PCB support can be adjusted in any direction with external universal fixture |
Temperature control | K-type thermocouple, closed loop controlled |
Temp accuracy | ±2°C |
PCB size | Max 360mm*350mm Min20mm*20mm |
BGA chip | 5*5~55*55mm |
Minimum chip spacing | 0.15mm |
Temperature Sensor | 1(optional) |
Net weight | 30kg |
DH-A08 Main Features:
lThree independent heaters all can set 8 segments heating, cooling and constant temperature, save up to ten temperature profiles. IR preheat area can be controlled according to PCB size
lK sensor close loop control and automatic temperature compensation system. It combines with temperature module, which enables temperature accuracy to ±2°C
lMoveable heater, easy to operate.
lHot air nozzles, 360 degree rotation, easy to install and replace, customized is available.
lV-groove PCB support for rapid, convenience and accurate positioning that fits for all kinds of PCB board.
lPowerful cross flow fan, cooling the PCB board efficient after heating, to prevent it from deformation.
lSound hint system. There is an alarm before the completion of each desoldering and soldering.
lCE certification, with emergency switch and automatic power-off protection device when emergency
Several details about DH-A08:
Accessories
cleaning workshop and advanced machines
CE certification
