Home > Products > Prime Power - 20KW--200KW > 40KW Huafeng diesel generator
40KW Huafeng diesel generator
- 200 Set / Sets per Month
- Qingdao
- T/T L/C D/P D/A
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Shanhua | |
| Model Number | HL40GF | Output Type | AC Three Phase | |
| Speed | 1500RPM | Frequency | 50HZ | |
| Rated Power | 40KW | Rated Voltage | 400/230/380/220/450/415V | |
| Rated Current | 72A |
Product Description
Specifications
Engine Brand:HuafengAlternator:Marathon/Stamford/Shanhua
Control System:Deepsea/Smartgen/ComAp
40KW Huafeng soundproof diesel generator
Genset :
Model: HL40GF
Prime Power (KVA / KW): 50/40
Standby Power (KVA / KW): 55/44
Rated Ammeter (A): 72
Dimensions (mm) (L×W×H): 1720 ×760 ×1300
Net Weight (kg):750
Engine:
Manufacturer: Weichaihuafeng
Model: K4100ZD-1
Number of cylinders: 4
Aspiration: Turbo
Bore×Store(mm): 100 × 115
Compression ratio: 19:1
Displacement, total (L):
Speed Governor: Mechanical
Cooling System: Water Cooled
Fuel Consumption at 100% Load (g/kw. h): 210
Starting Method: 12V DC Starter
Alternator:
STAMFORD, MARATHON, SHANHUA, 3 Phase and 4 Wires, 100% copper wire Brushless, Self-exciting, IP21-IP23, and Insulation Class: H
