150*150*22 Round hole Porous ceramic filter,Alumina ceramic rod for casting
- Tianjin
You May Like
-
133*133*20 Round hole ceramic filter plates for casting foundry, porous filter
-
120*120*20 Round hole honeycomb ceramics
-
120*85*15 Round hole Porous ceramic filter extruded honeycomb ceramics
-
100*100*20 honeycomb ceramic filter for casting foundry,
-
100*75*15 Round hole honeycomb ceramic filter for grey iron casting
-
98*98*12.7 Round hole honeycomb ceramics for ductile iron casting
Product Details
| Place of Origin | China | Type | Ceramic Plates | |
| Model Number | 150*150*22 | Brand Name | Elite |
Product Description
Size(mm) | Thickness | Aperature | Opening ratio | Effective filterarea | Flow velocity(kg/S) | Filter capacity(kg) | ||
Grey iron | Ductile iron | Grey iron | Ductile iron | |||||
37×37 | 12.5 | Φ2.3 | 62 | 1073 | 3~4 | 1~3 | 25~50 | 14~30 |
40×40 | 12.5 | Φ1.5 | 56 | 1280 | 2~3 | 0.5~1 | 35~60 | 7~20 |
12.5 | Φ2.3 | 60 | 1280 | 3~5 | 1~2 | 53~90 | 16~44 | |
50×50 | 12.5 | Φ1.5 | 49 | 1929 | 3~5 | 1~2 | 53~89 | 10~30 |
12.5 | Φ2.3 | 60 | 1929 | 3~6 | 1~4 | 73~123 | 19~54 | |
55.1×55.1 | 12.7 | Φ1.5 | 56 | 2475 | 4~6 | 1~3 | 65~110 | 13~36 |
12.7 | Φ2.3 | 61 | 2475 | 6~10 | 2~5 | 105~180 | 29~80 | |
60×60 | 12.5 | Φ2.3 | 60 | 2693 | 8~13 | 2~6 | 136~231 | 37~100 |
66.8×66.8 | 12.7 | Φ1.5 | 56 | 3564 | 7~13 | 2~5 | 130~230 | 15~45 |
12.7 | Φ1.8 | 55 | 3564 | 5~9 | 2~6 | 100~175 | 20~60 | |
12.7 | Φ2.3 | 62 | 3564 | 9~16 | 3~7 | 159~270 | 33~93 | |
75×75 | 22 | Φ2.5 | 58 | 4490 | 13~22 | 4~10 | 224~380 | 47~133 |
12.7 | Φ2.3 | 53 | 4490 | 13~22 | 4~10 | 224~380 | 47~133 | |
81.8×81.8 | 12.7 | Φ1.8 | 52 | 5740 | 8~13 | 3~7 | 140~250 | 50~120 |
12.7 | Φ2.5 | 61 | 5740 | 16~27 | 6~13 | 260~380 | 50~130 | |
98.3×98.3 | 12.7 | Φ2.5 | 60 | 8090 | 24~40 | 8~20 | 300~490 | 65~180 |
21.3 | Φ2.5 | 60 | 8090 | 24~40 | 8~20 | 300~490 | 65~180 | |
21.3 | Φ3.8 | 53 | 8090 | 30~65 | 10~25 | 300~510 | 70~185 | |
120×120 | 20 | Φ2.5 | 54 | 8700 | 28~50 | 10~20 | 300~550 | 75~200 |
133×133 | 21.5 | Φ2.5 | 56 | 15030 | 30~55 | 12~30 | 650~1150 | 145~400 |
21.5 | Φ3.8 | 64 | 15030 | 90~130 | 30~65 | 1400~2200 | 600~1100 | |
21.5 | Φ5 | 62 | 15030 | 130~200 | 50~100 | 2600~4000 | 1100~2000 | |
