40KW Yuchai Diesel Generator Set 380 Volt

40KW Yuchai diesel generator set 380 volt

Specification of genset

Genset model:HL30GF

Prime power: 30KW/37.5KVA

Standby power: 33KW/42KVA

Power factor: 0.8

Rated Voltage: 400/230V

Rated frequency (HZ): 50

Dimensions (mm) (L×W×H): 1860×700×1050

Weight (kg): 720

Specification of diesel engine

Engine Model: YC4D60-D21

Manufacturer: YUCHAI

Governor: M/E

Air intake way: NA

Cylinders/Arrangement: 4/L

Bore× Stroke(MM): 108×115

Fuel Consumption Rate(L/h): 205

Lubricating oil capacity(L): 12

Coolant capacity (L): NA

Compression ratio: 17:1

Displacement, total (L): 4.214

Net weight (kg): 370

Engine speed (rpm): 1500

Max Power (kW): 44

Starting Method: DC12V electrical starting

Specification of alternator

Alternator model: HLF30

Connecting Type: 3 Phase and 4 Wires

Number of Bearing: 1

Protection Grade: IP21

Altitude: ≤1000m

Exciter Type: Brushless, Self-exciting, AVR automatic voltage regulating,100% Copper winding wire

Insulation Class: H

Telephone Influence Factor (TIF): ≤50

Voltage Regulation, Steady State: ≤±1%

Transient State Voltage: ≤-15%~+20%

Control System

Operating temperature: -20°C~60°C

Relative Humidity: 95%

Operating voltage: DC24V (range: 18-30V, pressure: 50V/5 mm )

Standard functions: Engine Control/Generator Monitoring/Generator Protection/

Engine Monitoring/Clear Text Display

Shutdown: Loss of Speed Signal,Alternator Under / Over Voltage,Alternator Under/ Over Frequency,

Mains Under / Over Voltage,Mains Under/ Over Frequency,Under / Over Speed,Low Oil Pressure,High Engine Temperature,Phase Sequence Electrical (Option),Earth Fault (Option)

Warning: Alternator Under / Over Voltage,Alternator Under/ Over Frequency,Mains Under / Over Voltage,Mains Under/ Over Frequency,Under / Over Speed,Low Oil Pressure Pre-Alarm,High Engine Temperature Pre-Alarm,High/Low Battery Voltage,Over-current,Periodic maintenance
