Home > Products > Special Autoclave > Textile Steaming Machine
Textile Steaming Machine
- Qingdao Port
- T/T
You May Like
Product Details
| Condition | New | Automatic Grade | Automatic | |
| Place of Origin | Shandong, China | Brand Name | SHENGBO | |
| Model Number | DL01-4.5B.3 | Voltage | 380V | |
| Dimension(L*W*H) | 5500*1800*2200mm | Weight | 1005kgs | |
| Certification | CE/ISO/CCC | Warranty | 1year, 1 year | |
Product Description
PREVIEW
1. Yarn steaming autoclave is widely used for textiles made by cotton, linen, hair, real silk, chemical fiber, etc.
2. Textiles can be shaped after being processed.
3. Moisture of products will be improved when temperature and vacuum reach some value, to reduce expansion rate of yarn. Meanwhile, hand feeling, glossiness tension and strength will be improved on some level.
SUITABLE USAGES
TECHNICAL PARAMETERS
1. Working Temperature: 60-150℃
2. Vacuum: 0-0.07Mpa
3. Loading Capacity: 300kg, 600kg, 1000kg, 1500kg
4. Heating Method: boiler steaming or electric heating water
5. Material: carbon steel Q345R
6. Insulation Layer: rock wool, fire prevention and thermal insulation
7. Insulation Thickness: 50mm
FEATURES
1. Curing time is shorter, save energy.
2. The quality is credibility and stabilization. Temperature and humidity are controlled accurately.
3. Investment cost is much lower than other exporters in China.
4. Widely used for all kinds of natural fiber yarn, synthetic fiber yarn, blended yarn, etc.
MODEL REFERENCE
Model | Operating Temperature (℃) | Vacuum (Mpa) | Inner Diameter (mm) | Effective Length (mm) | Loading Capacity (kg) | Control Manner | Heating Method | Dimension (L*W*H) (MM) | Total Wight (kg) |
DL1.2-4.C.2 | 60-120 70-150 | -0.07 | 1200 | 2200 | 250 | automatic | steam | 3500*1600*1650 | 1900 |
DL1.5-5.5C.2 | 60-120 70-150 | -0.07 | 1500 | 2600 | 500 | automatic | steam | 4100*2000*2050 | 1600 |
DL1.5-7.C.2 | 60-120 70-150 | -0.07 | 1500 | 3600 | 700 | automatic | steam | 5000*2000*2050 | 3000 |
DL1.5-10C.2 | 60-120 70-150 | -0.07 | 1500 | 5200 | 1000 | automatic | steam | 6200*2000*2050 | 3800 |
DL1.8-10C.2 | 60-120 70-150 | -0.07 | 1800 | 3600 | 1000 | automatic | steam | 4700*2300*2650 | 3900 |
| |||||||||
AUTOCLAVE INSIDE
1. Boiler steam heating
2. Electric heat water
VARIOUS QUALIFICATON CERTIFICATION
