Home > Products > New Products > A090VW01 V0 AUO LCD PANEL
A090VW01 V0 AUO LCD PANEL
You May Like
Product Details
| Place of Origin | Taiwan, China | Brand Name | AUO | |
| Model Number | A090VW01 V0 | Type | TFT |
Product Description
Screen Size inch 9.0(Diagonal)
2 Display Resolution dot 800×480RGB(V)
3 Overall Dimension mm 211.7(H) × 125(V) × 4.6(T) Note 1
4 Active Area mm 199.2(H)×110.16(V)
5 Pixel Pitch mm 0.249(H)×0.2295(V)
6 Color Configuration -- R. G. B. Stripe Note 2
7 Color Depth -- 16.7M Colors Note 3
8 NTSC Ratio % 48%
9 Display Mode -- Normally White
10 Panel surface Treatment -- Anti-Glare, 3H
11 Weight g 220
12 LCD Module Power Consumption W 2.1W
Viewing direction 6 o’clock (gray inversion
