tig mma mig mag Cutting Machine CUT-60
- 2000 Piece / Pieces per Month
- NINGBO SHANGHAI
- T/T D/P D/A
You May Like
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | stonote ruiling | Model Number | CUT-60 | |
| Arc Current | 60A | Rated Duty Cycle | 60% | |
| Motor Type | DC Motor | Dimensions | 480*205*355 | |
| Usage | Cutting stainless steel | Voltage | 380V | |
| Certification | CE ISO9001 CCC | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.Cutting capacity increased 1.8 times higher in cutting speed compare with acetylene cutting.2. Thick metal plate can be cut
Detailed Product Description
1. Cutting capacity increased 1.8 times speed compare with flame one
2.Thick metal plate can be cut easily and quickly
3.Suitable for cutting stainless steel, copper, iron and aluminum metal
4.Simple operation, smooth cutting surface
ITEM
|
CUT-30 |
CUT-40 |
CUT-60 |
CUT-100 |
CUT-120 |
Voltage/frequency | AC220V±10%50Hz/60Hz | AC220V± 10%50Hz/60Hz | AC380V± 10%50Hz/60Hz | AC380V± 10%50Hz/60Hz | AC380V± 10%50Hz/60Hz |
Input power capacity(KVA) | 4 | 6 | 9 | 17 | 20 |
Current range(A) | 10-30 | 10-40 | 20-60 | 20-100 | 20-120 |
Rated Duty cycle(%) | 60 | 60 | 60 | 60 | 60 |
Rated output voltage(V) | 92 | 92 | 104 | 120 | 128 |
No-load voltage(V) | 230 | 230 | 236 | 270 | 270 |
Efficiency(%) | 85 | 85 | 85 | 85 | 85 |
Power factor(COS) | 0.93 | 0.93 | 0.93 | 0.93 | 0.93 |
Suggested air pressure(kg) | 4 | 4 | 4.5 | 5 | 5.5 |
Arc starting | Torch | torch | torch | HF | HF |
Gross weight(kg) | 12 | 12 | 23 | 40 | 40 |
Protection class | IP21 | IP21 | IP21 | IP21 | IP21 |
Net weight(kg) | 8.5 | 8.8 | 12 | 30 | 32 |
Insulation class | F | F | B | F | F |
Suggested exhaust volume of air compressor(m3/min) | 0.17 | 0.17 | 0.25 | 0.36 | 0.48 |
Dimension(mm) | 371*155*295 | 371*155*295 | 480*205*355 | 580*334*480 | 580*334*480 |
