Highly-efficient Japan Bearings Ntn Made in Japan

Specifications

   Highly-efficient japan bearings ntn made in Japan

• Reliable Japan quality

• High-precision

• Extensive inventory

 |||| Product Dscription ||||

Deep Groove Ball Bearings
The most common type of bearing,

deep groove ball bearings are widely used in a variety of fields.

Deep groove ball bearings include shield bearings

and sealed bearings with grease make them easier to use.

Deep groove ball bearings also include bearings

with a locating snap-ring to facilitate positioning when mounting the outer ring,

expansion compensating bearings which absorb dimension variation

of the bearing fitting surface due to housing temperature,

and TAB bearings that are able to withstand contamination in the lubricating oil.

Design features and special characteristics

Deep groove ball bearings are very widely used.

A deep groove is formed on each inner and outer ring of the bearing enabling them

to sustain radial and axial loads in either direction as well as the complex loads

which result from the combination of these forces.

Deep groove ball bearings are suitable for high speed applications.

In addition to unsealed bearings, deep groove ball bearings include ball bearings

with greased sealed inside (sealed or shielded) and bearings with a snap ring

that simplify structure around the bearing and design.

Table 1 shows the construction and special characteristics

of various sealed deep groove ball bearings.

|||| Company Information||||


Daiki Sangyo Co., Ltd. was founded in 1939 as a specialist dealer in industrial equipment.

Since then, we have continued to advance along with Japan's world-class manufacturing culture.

We mainly deal in industrial machinery components such as transmission equipment,

and we have over 60 years of history in the business with a strong sales track record.

Currently, we have 15 branches in Japan, and we have a vast inventory of products

at our distribution warehouses sourced from the manufacturers.

As an industrial equipment solutions company, we hope to continue to provide

high quality Japanese products not only in Japan, but also worldwide.
