95% High Alumina Ceramic Hemisphere Tiles For Chute Lining Plates
- Qingdao port
- T/T D/P D/A
You May Like
-
Zirconia Toughened Alumina Ceramic Bricks For Impact Resistant Chute Lining
-
Bolt-in 95% High Alumina Cermaic Lining Rubber Mat Steel Backed Panel
-
Impact-Resistant Ceramic Tiles For Chute Lining
-
Zirconia Toughened Alumina Cceramic Bricks For Chute Lining
-
Bolt-in High Alumina Wear Resistant Tiles Rubber Mat Backed Steel Panel
-
Wear And Impact Resistant ZTA Ceramic Lining For Conveyor Transfer Chute
Product Details
| Place of Origin | Shandong, China | Type | Ceramic Parts | |
| Application | Industrial Ceramic | Material | Alumina Ceramic | |
| Model Number | SHC-K | Brand Name | SINHO |
Product Description
SHC-K Shock resistant ceramic lining
SHC-K Shock resistant ceramic through advanced screw welding technology fixed on the equipment, and then spin on the ceramic cover, forming a strong wear resistant lining.
Optional material
Ceramic: SHC ceramic /SHN ceramic /SHA ceramic nano ceramic
Viscose: SHV-200/SHV-300/SHV-500/SHV-800
Using temperature
Below 800℃
Suitable medium
Less than 200mm particles of coal, coke, ore, cement clinker, sinter etc.
Application
It is suitable for anti wear of thermal power, steel, cement, coal, port, mining, chemical industry, material conveying chute hopper and other equipment. Especially applied in the chute,material bins/hoppers,skirt
liners and bucket wheel Stacker&Reclaimers.
Regular size
Thickness 20/25/30/50/70mm
Super wear resistant
Vivtorinox hardness is up to as high as 1800, extending the service life of the equipment more than 15 times.
Shandong SINHO will design and manufacture the custom-made products and provide tailor-made solution to every individual wear problem in specific conditions. It is very appriated to provide your equipment drawings and site condition features, so we will provide the most suitable anti abrasion and wear program for you.
The Technical Specifications
The performences | Unit | No. |
| Content of AL2O3 | % | ≥95% |
| Density | g/cm3 | 3.7 |
| Rockwell hardness | HRA | 88 |
| Rupturing toughness | MPa.m1/2 | 4 |
| Compression-resistant strength | MPa | ≥850 |
| Bend-resistant | MPa | 300 |
| Thermal conductivity |
W/m.K
| 24 |
Thermal expansion coefficient | 10-6 m/m.K | 5.0-8.3
|
