Automatic Triangle Pocket Packing Machine DXD-80S

Description

Product explanation
Is suitable granulated to  food, the shrimp strip, the peanut, the puffed rice, the rolled cat, the melon seed, the fruit jelly, the white sugar, the salt and so on, the shape, the liquid food triangle packing.

Main characteristic
1. uses the Japanese Mitsubishi PLC programmable control, and is equipped with the Chinese and English body man-machine operation contact surface, thus causes the equipment operation simply, adjustment convenient, the automaticity is high.
2. warm uses the intelligence to control a meter pair of road to control horizontally, vertical seals the temperature, thus causes the seal reliably, the leak-proof quality good, the bag smooth, fine, the packing efficiency is high.
3. systems bags system uses step  machine subdivides the technology, the automatic tracking, locates the sack the color code, with ease completes the system bag the operation, the adjustment, the speed quickly, the movement steady, the noise is low.
4. uses the advanced intelligence photoelectric follow-up and the automatic compensation function, guaranteed the sack two-sided printing design automatically to the version, enhances the packing material utilization ratio.
5. in fixed scope stepless adjustment packing speed, localization yawn engine off.
6. can automatically complete the system bag, the measurement, fills, seals gathers, shuts off, the register, the printing batch number and so on completely works.

7. end products shapes assume the triangle, novel is unique.

8. independent feedings, may in bag of center packages enter the many kinds of goods.
Main technical parameter
Packing speed: 20-60 bag of/minutes
Measurement scope: (1-50ml)
System bag length: 50-120mm
System bag width: 40-80mm
Power source: 380V, 50HZ three-phase
Total output: 900W
Weight: 185kg
Contour: The long 800× width 700× is high 1,550
