EKEMP YK600 Card Reader Mini Reader Restaurant Cash Counter

EKEMP YK600 Card Reader Mini Reader Restaurant Cash Counter

Brief introduction:

EKEMP YK600 Card Reader Mini Reader Restaurant Cash Counter

Memory

9 MB FLASH, 256KB SRAM

LED Display
2.4’ inch TFT,320*240,LED high brightness back light, supports digital signatures

Keyboard
19 keys,10 numeric keys/letter keys,8 function keys,1 ON/OFF button

Magnetic stripe card reader
Meet standard ISO7811,ISO7812,1/2/3 tracks, supports bi-directional swiping

IC card reader
Support one IC card slot,meet ISO 7816,PBOC3.0,EMV standard

Contactless card reader
Supports 13.56MHZ, ISO14443 Type A/B, Mifare, NFC (optional)

SAM/SIM slot
One PSAM slot ,meet standard ISO 7816,one SIM slot

Safety
Hardware Encryption,pay with ANSI X9.8/ISO9564,ANSI X9.8/ISO8731, 3DES,RSA,etc.

Thermal Printer
High speed and low noise thermal printer ,paper width: 58MM,  outside diameter: 30mm

Bar code Scanner
Internal 1D bar code or 2D code scanner ( optional)

Communication
GPRS wireless communication(standard),WIFI/Bluetooth (optional)

Peripheral Interface
One MIC USB(For charging),one MINI USB (For serial communication)

Power Adapter
Input :100~240VAC,50Hz/60Hz;  Out put: 5.0VDC,2A

Battery
Li-ion battery,2600mah,3.7V

Programming language
Standard C,supports secondary development

Dimension
178mm×82mm×59mm(length×width×height)

Weight:  300g

Work environment
Temperature 0℃~50℃ (32℉~122℉),
relative humidity 10%~90% (Non - Condensing)
Storage environment
Temperature -20℃~60℃ (-4℉~140℉),
relative humidity 5%~95% (Non - Condensing)
