Supply Aggregate Crusher Machinery in China Crushing Factory
- qingdao
- T/T L/C D/P D/A
You May Like
Product Details
| Condition | New | Type | Jaw Crusher | |
| Application | stone,ore,limestone,CACO3,ore,concrete,granite | Motor Type | AC Motor | |
| Power(W) | 30kw | Capacity(t/h) | 15-50 ton/hour | |
| Place of Origin | Shandong, China | Brand Name | Hysan | |
| Model Number | PE-250*1000 | Dimension(L*W*H) | 1550*1990*1370mm | |
| Weight | 5.6 ton | Certification | ISO9001-2008 | |
| Warranty | one year excluding wearing parts | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Supply aggregate crusher machinery in China crushing factory1. aggregate crusher
2. mini crusher for sale
3. ISO 9001
Applied Material
Technical Data
model
| Input size (long*width) (mm) | Output size (mm) | Biggest feeding granularity (mm) | Production (T/h) | Eccentric shaft speed (r/min) | Motor power (KW) | Size (long*width*high) (mm) | |
ZG-PE-250*400 | 250*400 | 20-60 | 200 | 8-16 | 300 | 15 | 1430*1316*1296 | |
ZG-PE-400*600 | 400*600 | 40-100 | 350 | 14-36 | 275 | 30 | 1700*1732*1656 | |
ZG-PE-500*750 | 500*750 | 50-120 | 400 | 30-80 | 250 | 55 | 1900*1876*1821 | |
ZG-PE-600*900 | 600*900 | 75-200 | 480 | 56-192 | 250 | 55 | 2280*2180*2380 | |
ZG-PE-800*1000 | 800*1000 | 80-200 | 600 | 70-195 | 250 | 75 | 2550*2280*2380 | |
ZG-PE-750*1060 | 750*1060 | 80-235 | 630 | 105-260 | 250 | 90 | 2655*2302*2900 | |
ZG-PE-900*1200 | 900*1200 | 95-265 | 750 | 150-500 | 220 | 110 | 3170*2900*3250 | |
ZG-PE-1100*1400 | 1100*1400 | 150-300 | 1000 | 350-800 | 180 | 160 | 4200*3020*3900 | |
ZG-PE-1200*1500 | 1200*1500 | 150-300 | 1100 | 400-1000 | 180 | 200 | 3800*3120*4155 | |
ZG-PE-500*1500 | 500*1500 | 50-120 | 400 | 60-160 | 300 | 90 | 2250*2680*1920 | |
| 250*400 | 20-60 | 210 | 8-16 | 300 | 15 | 1108*1090*1392 | |
PE-250*1000 | 250*1000 | 20-50 | 210 | 15-50 | 300 | 30 | 1550*1990*1370 | |
PE-250*1200 | 250*1200 | 20-60 | 210 | 20-70 | 250 | 37 | 1530*2285*1625 | |
PE-400*600 | 400*600 | 40-100 | 350 | 14-36 | 275 | 30 | 1650*1715*1591 | |
| 500*750 | 50-120 | 425 | 30-80 | 250 | 55 | 2250*1980*1920 | |
PE-600*900 | 600*900 | 75-200 | 500 | 56-192 | 250 | 55 | 2560*1840*2320 | |
PE-750*1060 | 750*1060 | 80-235 | 630 | 108-256 | 250 | 90 | 2380*2550*2800 | |
PE-900*1200 | 900*1200 | 95-265 | 750 | 186-398 | 220 | 110 | 2960*2930*3265 | |
ZG-PEX-150*750 | 150*750 | 10-40 | 120 | 8-25 | 320 | 15 | 1210*1572*1045 | |
ZG-PEX-250*1000 | 250*1000 | 20-50 | 210 | 15-50 | 330 | 30 | 1550*1990*1370 | |
ZG-PEX-250*1200 | 250*1200 | 20-60 | 210 | 20-70 | 320 | 37 | 1530*2285*1625 | |
ZG-PEX-300*1300 | 300*1300 | 30-80 | 250 | 30-90 | 330 | 45 | 1530*2380*1720 | |
ZG-PEX-300*1500 | 300*1500 | 35-100 | 250 | 40-120 | 320 | 55 | 1900*2600*1780 | |
ZG-PEX-350*750 | 350*750 | 20-80 | 300 | 30-52 | 320 | 37 | 1650*1680*1655 |
Technical data of aggregate crusher is just for reference.
The working part of the aggregate crusher is two pieces of jaw plate, one is stationary and fixed on the front wall of machine body, which is called fixed jaw, while the other one, swing jaw, making a crushing chamber with the fixed jaw, moves back and forth periodically. When separating, the material enters into the crushing chamber and then the particle drops out from the bottom; when combined, the material is crushed by the compressive force, buckling and split effect from the jaw plate. The jaw crusher series are used for the primary and secondary crushing of hard material. There are two types of crusher, including coarse jaw crusher and fine jaw crusher.
1. We are the aggregate crusher manufactory
Shandong Hysan technology Machinery CO., LTD are specialized in aggregate crusher for over 20 years, with lower price, good quality and assured full after service.
2.Professional quality control team
We have professional technology staff to control the processing of production and finished machine so that we can assure the quality of crusher and spare parts.
3. Quick feedback
Any mail or message will be replied within one day;
4. Service and training
We provide you with the prophase plan, process flow design and manufacture equipment according to your special demand. Besides, We will provide equipment operation training for you; We have a professional after-sale service team to promptly solve your problems. During the guarantee period, we will deliver the wear parts for free. Over the period, customers can get the lowest price of spare parts from us.
To choose the appropriate model for you, we need to know the following information:
1. What's the raw materials(such as granite) and its size(mm/inch)?
2. What's the discharging size? 0-5, 5-10, 10-15, 15-30mm?
3. What's the required Capacity(tons per hour or TPH)?
4. Other special requirements.
Packing and shipping
Standard Export Packaging and Shipping
The products should be processed to be rustproof and moisture proof before delivery. The small parts are packed into wooden crates; the big parts are wrapped by plastic sheeting.
Delivery time: 25 days.
Payment term: 1> L/C 2> T/T 3> D/P
