Home > Products > jaw crusher > China Shanghai Type Stone Jaw Crushers
China Shanghai Type Stone Jaw Crushers
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Jaw Crusher | |
| Application | Aggregate, mining, construction and etc. | Motor Type | AC Motor | |
| Power(W) | 55 | Capacity(t/h) | 56-192 | |
| Brand Name | hysan | Model Number | shanghaiPE-600*900 | |
| Dimension(L*W*H) | 2560*1840*2320 | Weight | 14.3 | |
| Certification | ISO9001-2008 | Warranty | one year excluding wearing parts | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
hysan Jaw Crushers1. Complete solution;
2. Full tech support;
3. Low cost;
4. Negotiable price.
China shanghai type Stone Jaw Crushers China shanghai type Stone Jaw Crushers
The jaw crushers has a feature of big crushing ratio, uniform finished product size, simple structure, reliable operation, easy maintenance, low operation cost. Jaw crusher is preferred equipment for the complete set of product line as the first step crusher.
China shanghai type Stone Jaw Crushers applications
The PE series jaw crusher is widely applied in mine, metallurgy,chemical industry, building, highway,water conservancy, light industry to crush or break various kinds of stones with compressive of not more than 350Mpa.
China shanghai type Stone Jaw Crushers working Principle
The PE serial jaw crusher mainly consists of main frame, movable( swing ) jaw, eccentric shaft, toggle plates etc. The electric motor passes power via V-belt pulley to the eccentric shaft to make the movable jaw moves in mesh, therefore, materials in crushing chamber can be crushed.
China shanghai type Stone Jaw Crushers main Features
The PE serial jaw crusher has the features of large crushing ratio, reliable performance, excellent structure and low consumption.
Stone Jaw Crushers Technical Parameters
modeL | Feeding port size (long×width)(mm) | Discharging Mouth size (mm) | Biggest feeding granularity (mm) | Production (T/h) | Eccentric shaft speed (r/min) | Motor power (KW) | Envelop dimensions (long×width×high) (mm) |
SHPE-400×600 | 400×600 | 40-100 | 350 | 14-36 | 275 | 30 | 1650×1715×1591 |
SHPE-500×750 | 500×750 | 50-120 | 425 | 30-80 | 250 | 55 | 2250×1980×1920 |
SHPE-600×900 | 600×900 | 75-200 | 500 | 56-192 | 250 | 55 | 2560×1840×2320 |
PEX-250×1000 | 250×1000 | 20-50 | 210 | 15-50 | 300 | 30 | 1550×1990×1370 |
PEX-250×1200 | 250×1200 | 20-60 | 210 | 20-70 | 250 | 37 | 1530×2285×1625 |
ZG-PE-250×400 | 250×400 | 20-60 | 200 | 8-16 | 300 | 15 | 1430×1316×1296 |
ZG-PE-400×600 | 400×600 | 40-100 | 350 | 14-36 | 275 | 30 | 1700×1732×1656 |
ZG-PE-500×750 | 500×750 | 50-120 | 400 | 30-80 | 250 | 55 | 1900×1876×1821 |
ZG-PE-600×900 | 600×900 | 75-200 | 480 | 56-192 | 250 | 55 | 2280×2245×2320 |
ZG-PE-800×1100 | 700×1100 | 80-200 | 600 | 70-195 | 250 | 75 | 2550×2280×2380 |
ZG-PE-750×1060 | 750×1060 | 80-235 | 630 | 105-195 | 250 | 90 | 2655×2302×3110 |
ZG-PE-900×1200 | 900×1200 | 95-265 | 750 | 90-220 | 220 | 110 | 3800×3160×3050 |
ZG-PE-1100×1400 | 1100×1400 | 150-300 | 1000 | 150-340 | 180 | 160 | 4200×3020×3900 |
ZG-PE-1200×1500 | 1200×1500 | 150-300 | 1100 | 200-500 | 180 | 200 | 4100×3120×4155 |
ZG-PEX-150×750 | 150×750 | 10-40 | 120 | 8-25 | 320 | 15 | 1210×1572×1045 |
ZG-PEX-250×1000 | 250×1000 | 20-50 | 210 | 15-50 | 330 | 30 | 1550×1990×1370 |
ZG-PEX-250×1200 | 250×1200 | 20-60 | 210 | 20-70 | 320 | 37 | 1530×2285×1625 |
ZG-PEX-300×1300 | 300×1300 | 30-80 | 250 | 30-90 | 330 | 45 | 1530×2380×1720 |
ZG-PEX-300×1500 | 300×1500 | 35-100 | 250 | 40-120 | 320 | 55 | 1900×2600×1780 |
ZG-PEX-350×750 | 350×750 | 20-80 | 300 | 30-52 | 320 | 37 | 1650×1680×1655 |
