Home > Products > Screen Printing Mesh > High Quality 200 Micron Woven Polyester Mesh Manufacture
High Quality 200 Micron Woven Polyester Mesh Manufacture
US$ 0.25 - 20
/ Square Meter
50 Square Meters(Min. Order)
- Tianjin or other ports
- T/T Credit Card PayPal
You May Like
-
High Tension Micron Yellow Dye 70t Polyester Mesh
-
High Tension 100 Micron Yellow Dye Polyester Mesh
-
High Quality 200 Micron Yellow Silver Polyester Mesh Fabric
-
High Quality Acoustic Loudspeaker Mesh Fabric
-
High Quality Polyester 25 Micron Silk Screen
-
100% Polyester Filter Mesh 30 Meters 100% Polyester
Product Details
| Place of Origin | Hebei, China | Brand Name | Shangshai | |
| Model Number | Filter mesh | Usage | Liquid Filter | |
| Type | Filter Elements | Material | Polyester | |
| Hole Shape | Square | Filter Rating | 21%-56% | |
| Thickness | 85-1000um | Length | customized | |
| Width | cunstomized |
Product Description
Fine quality polyester screen printing mesh for line artwork
When the amount is more than $1,000. you can place the order by Alibaba directly.
We do top quality nylon mesh. test every meter and guarantee thread diameter
All the mesh are food grade
Polyester mesh:
| Material | 100% polyester |
| Weave | Plain |
| Mesh Count | 18-420mesh/inch(7-165T) |
| Thread Diameter | 31-350um |
| Mesh Opening | 25-1100um |
| Width | 1150mm,1270mm,1580mm, 1650mm,2600mm,3200mm,3650mm(Max) |
| Color | White, Yellow, Orange, Black |
| size, shape, packing can be customized | |
Features:
1.smooth surface, good ink permeability
2.good abrasion resistance
3.high flexibility and easy cleaning
4.long service life
Techincal specifications of nylon mesh:
| Spcification(/cm) | Mesh count(mesh/inch) | Thread Dimeter(um) | Mesh opening(um) | Aperture ratio(%) | Thickness(um) | Amount of theoretical ink(cm³/m2) |
| 4 | 10 | 550 | 1931 | 60 | 1100 | 251 |
| 5 | 13 | 500 | 1500 | 56 | 1000 | 308 |
| 6 | 15 | 400 | 1267 | 58 | 840 | 228 |
| 7 | 18 | 350 | 1079 | 57 | 640 | 209 |
| 8 | 20 | 350 | 900 | 52 | 645 | 232 |
| 9 | 24 | 200 | 911 | 67 | 370 | 92 |
| 9 | 24 | 250 | 861 | 60 | 460 | 145 |
| 9 | 24 | 300 | 811 | 53 | 570 | 205 |
| 10 | 25 | 250 | 750 | 56 | 530 | 148 |
| 12 | 30 | 300 | 533 | 41 | 495 | 256 |
| 14 | 35 | 200 | 514 | 52 | 380 | 135 |
| 16 | 40 | 200 | 425 | 46 | 400 | 155 |
| 16 | 40 | 250 | 375 | 36 | 420 | 240 |
| 17 | 42 | 200 | 388 | 44 | 380 | 160 |
| 18 | 45 | 220 | 366 | 37 | 400 | 207 |
| 20 | 50 | 200 | 300 | 36 | 375 | 190 |
| 24 | 60 | 150 | 267 | 41 | 305 | 130 |
| 28 | 70 | 150 | 207 | 34 | 278 | 150 |
| 30 | 76 | 120 | 213 | 41 | 230 | 105 |
| 32 | 80 | 100 | 213 | 46 | 240 | 77 |
| 36 | 90 | 100 | 178 | 41 | 195 | 86 |
| 40 | 100 | 100 | 150 | 36 | 192 | 95 |
| 44 | 110 | 100 | 127 | 31 | 175 | 105 |
| 48 | 120 | 80 | 128 | 38 | 150 | 73 |
| 56 | 142 | 60 | 120 | 44 | 110 | 48 |
| 59 | 150 | 60 | 110 | 42 | 98 | 50 |
| 64 | 163 | 60 | 96 | 38 | 120 | 55 |
| 72 | 183 | 50 | 89 | 41 | 90 | 44 |
| 80 | 203 | 50 | 75 | 36 | 93 | 48 |
| 88 | 224 | 40 | 74 | 42 | 65 | 34 |
| 96 | 244 | 40 | 64 | 38 | 76 | 37 |
| 100 | 254 | 40 | 60 | 36 | 78 | 39 |
| 104 | 264 | 40 | 56 | 34 | 79 | 40 |
| 120 | 305 | 40 | 43 | 27 | 80 | 46 |
| 130 | 330 | 40 | 34 | 20 | 85 | 29 |
| 140 | 355 | 38 | 33 | 21 | 85 | 28 |
Remark:The above are theoretic data for reference only.
Production Process
Applications
Top-class Machines
Quality Assurance
Packing
1.30-70m/roll in PVC bag
2.2-8 rolls per carton
3.waterproof bags outside
4.package belt strengthen
Delivery Ways
Contact Us
- Yantai Shangshai Wire Mesh Products Co., Ltd.
- Contact nameSales Han Chat Now
- Phone86-0535-6646021
- AddressNo.3. ZHUJI West Road, Yantai, Shandong
