SKMG50 full hydraulic anchoring borehole drilling rig

FOB Price

Negotiable / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Other, impact drilling rig
Power Type	Electric	Place of Origin	Hubei, China
Brand Name	shoukai	Model Number	SKMG50
Usage	Ore	Voltage	380v
Power(W)	5.5KW / 7.5KW	Dimension(LWH)	3000x780x1360mm
Weight	1300kg	Certification	ISO9001-2008
Warranty	1 year	After-sales Service Provided	Engineers available to service machinery overseas

1,full hydraulic power head
2,can be used in water conservancy, railway and road side slope
3,for anchoring hole, drain hole..

1, convenient up and down adjust mechanism

The up and down hydro-cylinder can adjust the angle of guide rail fast to satisfy drilling requirements from different angles.

The compensation hydro-cylinder can guarantee the guide rail to stand vertically on the ground when making vertical drilling.

2, strong power head

3, power components

3-phase asynchronous electric motor and double connect gear oil pump provide power for drillng rig.

4, centralized control bench

The control bench far from drilling rig can protect the safety of operator.

The centralized control metal stick makes the controlling of drilling rig easy and convenience.

Advanced hydraulic system can realize drilling rig rotating and feeding fast.

model	SKMG50
bore depth	25~70m
bore diameter	90~165mm
drilling rod diameter	Φ76 x 1500mm, Φ89 x 1500mm
propulsion rotating angle	0~90°
power head rotating speed	0~70rpm
power head torque	2500N·m
propulsion stroke	1800mm
compensation stroke	500mm
max. lifting force	27.5KN
max. propulsion force	23.5KN
hydraulic system rated pressure	17~18MPa
weight	1300kg
overall dimension	3000x780x1360mm
