0.28mm CATV Coaxial TCCA Electric Wire
- shanghai
- T/T L/C D/P D/A
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Lianwang | |
| Model Number | CL06 | Type | Bare | |
| Application | Other, Electrical wire | Conductor Material | Copper Clad Aluminum | |
| Conductor Type | Solid | Insulation Material | Other, uninsulated |
Product Description
Used for produce braiding wire,which suit for flexible connections of electrical installation,switch device;
Used for production of wave-proof cover,which suit for prevent radio frequency interference or protection of shielding copper braided cover;
Used for the various shielded network cable,a varitty of multicore shielded signal cable and so on;
Tinned CCA /Tinned CCAM wire is a new shielding materials which made of CCA /electric property and mechanical property among copper wir and aluminum wire.It commbines the good conductivity of the copper and light weight of aluminum,it owns good shielding performance,easy to weld,not easy to oxidation.
| Copper volume | 10-15% |
| Specific gravity | 3.32-3.63g/cm3 |
| Conductivity | 63-65%IACS |
| Tensile strength | 90-120Mpa |
| Resistivity | 0.027Ω.mm2/m |
| Elongation | >10% |
