SF110-TC 110KW/150HP 13 BAR AUGUST Variable Frequency Air Cooled Screw Air Compressor Variable Frequency Inverter

FOB Price

US$ 2,000 - 100,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Rotary
Configuration	Stationary	Power Source	AC Power
Lubrication Style	Lubricated	Mute	No
Place of Origin	Zhejiang, China	Brand Name	AUGUST
Model Number	SF110-TC	Voltage	380V
Dimension(LWH)	2000X1200X1798 MM	Weight	2500 KG
Certification	ISO 9001/ISO14001/ CE	Warranty	18 Months
After-sales Service Provided	Engineers available to service machinery overseas

SF110-TC 110KW/150HP 13 BAR AUGUST variable frequency air cooled screw air compressor variable frequency inverter

Air Cooled
Twin Screw Single Stage Air End – AUGUST- Brand
5 Year Rotor Warranty
45,000-50,000 Working Hours Engineered Lifetime
SKF Explorer Bearings (mainly)
Energy Saving micro control system, fully automated operation
Easy Maintenance
Low-noise operation, closed cabinet structure, Noise Reducing Dumping Mats made of fire-retardant materials
Direct Coupling Drive SFG37-SFA45 Displayed drawing is for reference only and might be different in advanced model. Please ask for detailed drawing if and when required.
Efficient, safe and reliable fully enclosed motor drive (IP54, F class / IP55 optional)
Energy Saving Air end 5:6 Helix
Networkable Link between Compressors / Grouping with on-line, remote monitoring and DSC network functions
High precision heavy duty intake filter 1μm, 99.9% efficiency
Optimized Oil Separation System residual oil rate 1-3mg/m3
Low Speed Air end Operation
Automatic Control of Functions / Maintenance Indicator
English language display, easy operation, running status at a glance, running real-time monitoring data
Pressure and Temperature Control and Protection
Start Up Protection ( Current Spike Free)
English Language Display / English Language Manual

Model	SF110-TA	SF110T-B	SF110T-C	SF110T-D
Free air delivery(m3/min)	21.00	17.50	14.50	20.00
cfm	742	618	512	706
l/s	350	292	242	333
Discharge pressure(MPa)	0.70	1.00	1.30	0.80
bar	7.00	10.00	13.00	8.00
psig	101.50	145.00	188.50	116.00
Ambient temperature(℃)	-5~+40
Cooling method	Air cooling
Air supply temperature (℃)	Less Than Ambient temperature +15℃
Drive method	Direct Coupling Drive
Start method	Star delta start
Noise dB(A)±3	80
Power (kW/HP)	110/150
Overall dimension (mm)	2500×1450×2000
Weight (kg)	2500.00
Air supply out (Inch)	2 1/2"
