Home > Products > Concrete Pump > Professional Manufacturer of HBT Series Concrete Pump for Sale in USA,
Professional Manufacturer of HBT Series Concrete Pump for Sale in USA,
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
Condition | New | Power Type | Diesel | |
Place of Origin | Jiangsu, China | Brand Name | DOTO | |
Model Number | HBT series trailer mounted | Power(W) | 90KW | |
Weight | 5800KG | Dimension(L*W*H) | 6300*2048*2138MM | |
Certification | ISO,CE | Warranty | WITHIN TWO YEARS | |
After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.trailer mounted concrete pumplevel hydraulic system
3.imported hydraulic hose
4.pump with high configuration
Product name
HBT series trailer mounted used concrete pump for sale in USA
Product introduction
The machine is excellent modernized concrete machinery developed with aid of advanced technology at home and aboard. They are made up of imported components at all the spot parts, suited for concrete pumping working onto height and distance in various construction sites such as buildings, bridges and tunnels, irrigations, airports, seaports and industrial grounds etc.
Specifications:
Model Parameter | HBTS50 | HBTS60 | |
Max.theo Output | M3/h | 60/40 | 75/45 |
Max. concrete Pressure | MPa | 8/13 | 8/13 |
Max. theo Conveying Distance Horizontal/Vertical | m | 800/200 | 800/200 |
Delivery Cylinder Diameter/Stroke | mm | Φ200/1600 | Φ200/1800 |
Delivery Cylinder Piston/Rod/Stroke | mm | Φ125/Φ80/1600 | Φ125/Φ80/1800 |
Driver Power | KW | 75 | 90 |
Hopper Capacity | m3 | 0.68 | 0.68 |
Tank Capacity | L | 580 | 600 |
Dimension | mm | 6180*2000*2005 | 6300*2048*2138 |
Weight | kg | 5500 | 5800 |
Features
1. Safe, specilized and ergonomic footstool and protected treadboard.
2. Electronical control system with more than 98% imported parts.
3. High specilized machinery with high reliability and long durability.
4.Most electrical appliance components of electrical system are imported, and PLC for control system,with reliable working,strong adaptability,and wired remote control;
5.Automatic lubricant filling device can eliminate the trouble of manual filling and extend the service life of the parts with less abrasion in the lubricants.
6.Cooling menthod adopts air cooling,with super strong chilling performance,keeping the oil temperature less than 600 under the air temperature of the whole year.
7.Hydraulic system adopts U return circuit, reversing is fast and efficient.
Details:
About company
Xuzhou Reman Construction Machinery Remanufacture Co., Ltd is located in xuzhou, the earliest place to research and development, production base of rotary drilling rigs in China. The company is specialized in selling new rotary drilling rigs, full -rotary drilling rigs and other piling machine; has complete industrial chain of researching and development, manufacturing and marketing various buckets, supply spare parts; also engages in evaluating and trading second-hand rotary drilling rigs.
Xuzhou Reman Construction Machinery Remanufacture Co., Ltd has many year's technical advantages, professional and experienced maintenance team; with moving maintenance shop--special vehicle for rigs field service; and advanced testing equipment, professional repairing workshop, spare parts warehouse, perfect testing methods and management system, all of these ensure the quality of our service and woke efficiency.
