Home > Products > New Products > OEM customed high-precision sheet metal gasket
OEM customed high-precision sheet metal gasket
- Shenzhen
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | Vantech | |
| Model Number | VAN-0083 | Material | Metal | |
| Shape | Flat Gasket | Standard or Nonstandard | Standard |
Product Description
metal gasket
heet metal components/deep drawn stamping carbon steel component,metal punched components /
Item | Description |
Material | Stainless steel, copper, silicon steel plate, aluminum, nickel, magnetic material and so on. |
Product thickness | 0.03mm—1.5mm |
Product size | 1*1mm—300*500mm |
Smallest open hole | Ø0.1mm |
Smallest line width | +/-0.025mm |
Product precision | +/-0.01, It’s generally 20% of material thickness. |
We professionally manufacture all kinds of metal components by etching process
Product thickness can be achieved between 0.03mm to 1.5mm.
Product size can be achieved between 1mm* 1mm to 600mm* 780mm.
Smallest open hole is Ø 0.1mm.
Smallest line width is 0.025mm.
Product precision is ± 0.01mm (common difference). Its generally 20% of material thickness.
We also provide imported stainless steel thin belts with many kinds of models such as 301,304,430.
If you have any interest in co-operation, pls contact us.
metal SUS304
Etching process:
Film(CAD output) →get the materials ready→Pre-treatment→DRY FILM(Lamination) →Exposure→Developing→Drying→Etching→Stripping → Checking,Packing,Delivery
Etching process:
Film(CAD output) →get the materials ready→Pre-treatment→DRY FILM(Lamination) →Exposure→Developing→Drying→Etching→Stripping → Checking,Packing,Delivery
