Brake Disc OE:42431-33010

1.Standard for casting is G3000. Standard for machining is SAE-J431.

2.All typical brake drums for trucks and automobile.

3.Many years of production experience.

4.We have stock of it in warehouse.

5.Good quality & competitive price.

6.Balanced,Safe braking,no noise,no shaking with the long life cycle.

7.Professional and passionate team.

1. Must meet G3000 for gray iron castings

2. Chemical Composition (Percent)

    * Total Carbon:            3.0 - 3.50%

    * Silicon:                       1.90 - 2.30%

    * Manganese:              0.60 - 0.90%

    * Phosphorus:             0.12% Max.

    * Sulfur:                         0.10% Max.

3. Microstructure:

    Graphite Structure: Predominantly type A, size 3-5.

    Matrix: Pearlistic with max.15 ferrite. Free from chill

4. Physical Properties

    Tensile Strength: Min. 200 N/mm

    Brinell Hardness: 190 ~ 230HB

Early disc for pure iron, material selection and did not change much, but with advances in materials science, most modern motorcycleusing iron as a material for disc, now more common in stainless steel. Wide range of stainless steel, is excellent because of rigidcast iron stainless steel, you can reduce the thickness of plates,
integral braking system to reduce the weight. In addition, thedurability of stainless steel plate is also higher than that of cast iron plates.
In addition to stainless steel, dish surface is also a priority. In order to create sufficient hardness and toughess, complex heat treatment is required to ensure excellent mechanical properties, andunfortunately,
most metals heat treatment quality is unable todistinguish with the naked eye, even without expensive modification of the selling price on the heattreated plate endlessly.
In partanecdotal surface gold lustre dish, this will most likely be used toprevent Rust plated handle, this plating mill came off, is not apermanent treatment.

Laizhou Haichen Machinery Co., Ltd is located in Shangdong province of China,specializing in producing brake discs, brake drums, brake pads and brake rotors. It was established in 2014. With a large workshop, professional production equipment, a world-leading technology and formulations. Blanks from the furnace to the production, processing, packaging and cleaning stop production, including the balance,the line of drilling, decromet, painting, galvanizing production and processing. OEM number or sample can be processed production. We have a strict and complete quality contral system which ensures that each product can meet customers' requiremnts.
