Car Accessories Brake Disc
- Qingdao
- T/T Credit Card
You May Like
Product Details
| Type | Other, Brake Discs, Vented | Material | G3000 | |
| Certification | TS16949/ISO9001 | Size | 300*54.5 | |
| Car Make | Ford | OE NO. | 1503287 | |
| Place of Origin | Shandong, China | Brand Name | HAICHEN | |
| Model Number | 1503287 |
Product Description
car accessories brake disc
1.Product Material:G3000
2. White / Color box.
3. Factory supplier
4. Low noise. No dust.
5. Long service life.
6. We have stock of it in warehouse.
7. Stable performance and thermal properties.
Internally Vented | |
Diameter [mm] | 300 |
Circle Diameter | 93 |
Thickness[mm] | 28 |
Min. Thickness[mm] | 25 |
Height[mm] | 54.5 |
Number of Holes | 5 |
1. Must meet G3000 for gray iron castings
2. Chemical Composition (Percent)
* Total Carbon: 3.0 - 3.50%
* Silicon: 1.90 - 2.30%
* Manganese: 0.60 - 0.90%
* Phosphorus: 0.12% Max.
* Sulfur: 0.10% Max.
3. Microstructure:
Graphite Structure: Predominantly type A, size 3-5.
Matrix: Pearlistic with max.15 ferrite. Free from chill
4. Physical Properties
Tensile Strength: Min. 200 N/mm
Brinell Hardness: 190 ~ 230
1.package:
Usually we use cartons and then put on pallets to pack;
we can also pack according to customer's special request.
2.Shipping:
Within 45 days after receiving deposit.
Samples for free, but you should pay for the express fee for the samples.
Laizhou Haichen Machinery Co., Ltd is located in Shangdong province of China,specializing in producing brake discs, brake drums, brake pads and brake rotors. It was established in 2014. With a large workshop, professional production equipment, a world-leading technology and formulations. Blanks from the furnace to the production, processing, packaging and cleaning stop production, including the balance,the line of drilling, decromet, painting, galvanizing production and processing. OEM number or sample can be processed production. We have a strict and complete quality contral system which ensures that each product can meet customers' requiremnts.

1.What’s your delivery time?
Within 45 days after receiving deposit.
2.With the package, can u provide the package according to my requirement?
Of course! Usually we provide with Plastic bags + Kraft paper box(customer brand color box)+Pallet
3.How much deposit do I pay for?
Usually it takes 30% payment as deposit.
4.What’s your payment terms?
We accept L/C and T/T or West Union through FOB QINGDAO
5.Could u provide fee samples?
Dear friend, for some samples are free, but you should pay for them.
6.How can I confirm the validity of products?
Don’t worry, we will provide OEM number for your to refer, what’s more, we will provide sample pictures for you to recheck!
7.What’s your goods quality? Will them be secondhand?
Our products all come from factory directly, they are totally new. We will firmly refuse to sell potential safety hazard products!!!
8.If I need the product on your website can't find, can you give me?
Of course, you need the product can email tell me, then I will give you as soon as possible to confirm the product.

Welcome to our store! If you have any question, please don't hesitate to let me know at any time. I will try my best to help you to resolve it. Your satisfaction is our biggest wish!
