Mini Size Optical Jack/ Photo Link / Optical Fiber Jack DQT(R)-020
- SHENZHEN/HK
You May Like
Product Details
| Brand Name | FOSEN | Model Number | mini size optical jack/ photo link / optical fiber jack DQT(R)-020 | |
| Include Display | Yes | Place of Origin | Guangdong, China |
Product Description
Specifications
1.mini size optical jack/ photo link / optical fiber jack DQT(R)-0202.over 10years manufacture
3.ROHS SGS ISO9001/14001
mini size optical jack/ photo link / optical fiber jack DQT(R)-020
Optical Fiber Transmitting Module Electro-Optical Characteristics
Parameter | Symbol | Conditions | MIN | TYP | MAX | Unit |
Peak emission wavelength | λp |
| … | 660 |
| nm |
Optical power output coupling with fiber | Pc | Refer to Fig.1 | -21 | -18 | -15 | dBm |
Dissipation current | Icc | Refer to Fig .2 | 3 | … | 7 | mA |
High level inprt voltage | ViH | Refer to Fig .2 | 2.0 | … | Vcc | V |
Low level input voltage | ViL | Refer to Fig .2 | … | … | 0.8 | V |
Low High delay time | tpLH | Refer to Fig .3 | … | … | 100 | ns |
High Low delay time | tpLH | Refer to Fig .3 | … | … | 100 | ns |
Pulse width distortion | tw | Refer to Fig .3 | -15 | … | +15 | ns |
Jitter | tj | Refer to Fig .3 | … | 1 | +15 | ns |
Optical Fiber Receiving Module Electro-Optical Characteristics
Parameter | Symbol | Conditions | MIN | TYP | MAX | Unit |
Peak emission wavelength | λp |
| … | 660 |
| nm |
Receiver input optical power level | Pc | Refer to Fig.3 | -24 | … | -13.5 | dBm |
Dissipation current | Icc | Refer to Fig .2 | 3 | … | 7 | mA |
High level inprt voltage | VoH | Refer to Fig .1 | 2.1 | … | … | V |
Low level input voltage | VoL | Refer to Fig .1 | … | 0.2 | 0.4 | V |
Rise time | tr | Refer to Fig .1 | … | 8 | 20 | ns |
Fall time | tr | Refer to Fig .1 | … | 8 | 20 | ns |
Low High delay time | tpLH | Refer to Fig .1 | … | … | 100 | ns |
High Low delay time | tpLH | Refer to Fig .1 | … | … | 100 | ns |
Pulse width distortion | tw | Refer to Fig .1 | -15 | … | +15 | ns |
Jitter | tj | Refer to Fig .1 | … | … | 15 | ns |
Mechanical Characteristics(Ta=25°C)
Parameter | Symbol | Conditions | MIN | TYP | MAX | Unit |
Insertion and Withdrawal Force | Fp | *1 | 3.9 | … | 40 | N |
Diagram:
