2014 New Design Doosan Daewoo Diesel Genset With CE Certificate

FOB Price

US$ 1 - 999,994 / Set

1 Set(Min. Order)

Port Shanghai Port
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	kangdong
Model Number	KD-500GF	Output Type	AC Three Phase
Speed	1500RPM	Frequency	50Hz
Rated Power	500kW	Rated Voltage	400/230V
Rated Current	900A

Product Description

2014 new design doosan daewoo diesel genset with CE certificate

1. Specification of genset
Gensets model				KD-500GF
Prime power(KW)				500
Rated voltage(V)				400 / 230
Rated current(A)				902
Rated frequency(HZ)				50
Rated Speed (rpm)				1500
Power Factor				0.8(lagging)
Dimensions(mm) (L×W×H)				3600x1420x1700
Net Weight(kg)				4200
2. Specification of diesel engine
Engine brand				Doosan Daewoo
Engine model				P222LE-S
Air Intake System				Turbocharged, Air/Air Cooling
Fuel System				BOSCH P type fuel pump
Cycle				Four stroke
Cylinder Arrangement				12 in ”V”
Displacement				21.927L
Bore×Stroke (mm×mm)				128 x 142
Compression Ratio				14.6:1
Rated RPM				1500rpm
Cooling System				Forced Water Cooling Cycle
Max. Standby Power at Rated RPM				603KW
Governor Type				Electronic
Starting Method				DC24V electrical starting
Exhaust System
Exhaust Gas Flow				93.9m³/min
Exhaust Temperature				598°C
Max Back Pressure				6kPa
Air Intake System
Max Intake Restriction				6.35kPa
Consumption				31.8m³/min
Air Flow				1286m³/min
Fuel System
100%(Standby Power) Load				130.0 L/h
75%( Standby Power) Load				99.8 L/h
50%( Standby Power) Load				68.3 L/h
Oil System
Total Oil Capacity				40L
Oil Consumption				≤4g/kwh
Engine Oil Tank Capacity				33L
Oil Pressure at Rated RPM				345-483kPa
Cooling System
Total Coolant Capacity				113L
Thermostat				71-85°C
Max Water Temperature				103°C
3. Specification of alternator
Alternator brand				Stamford
Alternator model				HCI544F-S
Excitation				Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire
Number of Phase				3
Connecting Type				3 Phase and 4 Wires
Number of Bearing				1
Power Factor				0.8
Protection Grade				IP23
Altitude				≤1000m
Insulation Class, Temperature Rise				H
Telephone Influence Factor (TIF)				≤50
THF				≤2%
Voltage Regulation, Steady State				≤±1%
Transient State Voltage				≤-15%~+20%
4. Specification of control Panel(with GU620A controller)
The control panel is AMF control panel, with the display of voltage,current, frequency, water temperature, oil pressure. The genset with low oil pressure,high water temperature,over speed,over load protection function.
The features of GU620A controller:
GU620A is a new generation Automatic control module for single Genset, which adopts bran-new outline configuration, focus on the requirements of customers, and perfectly improves the performance of controller. It fully meets the auto control requirements of different kinds of Genset for user or special assembly factory.
The module also monitors and protects the engine, indicating operational status, fault conditions and metering on the front panel LCD and LED’s.
