OEM Electronic Printed Circuit Board assembly PCBA
-
customized lead free double sidee calculator pcb board maker
-
Competitive price multilayer HASL electronic pcb printed circuit board
-
High quality 2oz 1.6mm led lighting pcb
-
multi-layer printed circuit board/8 layer pcb
-
customized rigid PCB /high quality pcb circuit board/pcb factory
Product Details
| Place of Origin | Guangdong, China | Brand Name | Sograce | |
| Model Number | Single Double Multilayer Pcb | Number of Layers | Other, 1-20 | |
| Base Material | FR-4 | Copper Thickness | 1oz, 0.5oz-5oz | |
| Board Thickness | 1.6mm | Min. Hole Size | 0.25mm, 0.2mm | |
| Min. Line Width | 0.1mm(Flash Gold)/0.15mm(HASL), 0.2mm | Min. Line Spacing | 0.075mm/0.1mm(3mil/4mil) | |
| Surface Finishing | HASL, immersion gold ,OSP,lead free HASL |
Product Description
single layer double layer multilayer pcb pcba from china
single layer double layer multilayer pcb pcba from china
Maximum Process PCB board Capability of Our Company
Files | Gerber, Protel, Powerpcb, Autocad, Cam350, etc |
Material | FR-4, Hi-Tg FR-4, Lead free Materials (RoHS Compliant) , CEM-3, CEM-1, Aluminium, High frequency Material (Rogers, Teflon, Taconic) |
Layer No. | 1 - 30 Layers |
Board thickness | 0.0075"(0.2mm)-0.125"(3.2mm) |
Board Thickness Tolerance | ±10% |
Copper thickness | 0.5OZ - 4OZ |
Impedance Control | ±10% |
Warpage | 0.075%-1.5% |
Peelable | 0.012"(0.3mm)-0.02’(0.5mm) |
Min Trace Width (a) | 0.005"(0.125mm) |
Min Space Width (b) | 0.005"(0.125mm) |
Min Annular Ring | 0.005"(0.125mm) |
SMD Pitch (a) | 0.012"(0.3mm) |
pcb with green solder mask and LF-FREE surface finishing BGA Pitch (b) | 0.027"(0.675mm) |
Regesiter torlerance | 0.05mm |
Min Solder Mask Dam (a) | 0.005"(0.125mm) |
Soldermask Clearance (b) | 0.005"(0.125mm) |
Min SMT Pad spacing (c) | 0.004"(0.1mm) |
Solder Mask Thickness | 0.0007"(0.018mm) |
Hole size | 0.01"(0.25mm)-- 0.257"(6.5mm) |
Hole Size Tol (+/-) | ±0.003"(±0.0762mm) |
Aspect Ratio | 6:01 |
Hole Registration | 0.004"(0.1mm) |
HASL | 2.5um |
Lead free HASL | 2.5um |
Immersion Gold | Nickel 3-7um Au:1-3u'' |
OSP | 0.2-0.5um |
Panel Outline Tol (+/-) | ±0.004''(±0.1mm) |
Beveling | 30°45° |
V-cut | 15° 30° 45° 60° |
Surface finish | HAL, HASL Lead Free, Immersion gold, Gold plating, Gold finger, immersion silver, immersion Tin, OSP, Carbon ink, |
Certificate | ROHS ISO9001:2000 TS16949 SGS UL |
Special requirements | Buried and blind vias, Impedance control, via plug, BGA soldering and gold finger |
single layer double layer multilayer pcb pcba from china
Electronic PCBA PCB assembly, PCB PCBA,PCB design in Sograce
Quote requirement for pcb and pcb assembly:
1) Gerber file and Bom list
2) Clear pics of pcba or pcba sample for us
3) Test method for PCBA
PCB Assembly Technical Request:
- Professional surface-mounting and Through-hole Technology
- Various sizes like 1206, 0805, 0603 components SMT Technology
- ICT ( In Circuit Test), FCT ( Functional Circuit Test) Technoloty
- PCB Assembly with UL, CE, FCC, RoHs approval
- Nitrogen gas reflow soldering technology for SMT
- High standard SMT & Solder Assembly Line
- High density interconnected board placement technology capacity
single layer double layer multilayer pcb pcba from china
single layer double layer multilayer pcb pcba from china
Packaging & Delivery
Packaging Details:
| The electronic PCBA PCB assembly, PCB PCBA,PCB design in Sograce is:
|
Delivery Detail:
|
3-5 working days for sample,7-10 working days for mass order
|
Q1: What's your minimum order quantity?
A1: Our MOQ is not the same based on different items. Small orders are also welcome.
Q2: what file we should offer?
A2: PCB:Gerber file is better,( Protel ,power pcb,PADs file); PCBA : Gerber file and BOM list.
Q3: What any other information should be offered except for file?
A3:Following specifications are needed for quotation:
a) Base material
b) Board thickness:
c) Copper thickness
d) Surface treatment:
e) color of solder mask and silkscreen
f) Quantity
Q4: Can you provide quick turn PCB?
A4:Yes,we can provide quick time service 1-2days.
Q5: What payment terms do you have?
A5: For small orders, we usually prefer Paypal and Western Union; For bigger order,pls pay by TT.
Q6: How about the shipping method?
A6:We have stable cooperationship with DHL, Fedex, EMS, UPS, TNT and other air flight way or sea freight company.Usually we will quote you the most reasonable shipping method according to your country, good types, weight and requested delivery time.
We shall appreciate if you could write us details of your order quantity, country, sea port/air port before you send us inquiry. In this way we can offer you the best and most accurate price.
Q7: I am very satisfied after I read your information, how can I start to purchase my order?
A7: Please click the "send" at the bottom of this page or contact our sales on Trade Manage online!
How to Contact Us?
Would like to know more about the product? Send us inquiry, click "Send" now!
single layer double layer multilayer pcb pcba from china
Sograce International Corporation Limited
is a professional PCB manufacturer for poducing all kinds of single side, double-side and multilayer pcb,
also provide assembly service with 10 years experience.We have a variety of advanced production equipments,
excellent engineering and technical personnels, accompany with the mature management and service system.
Our pcbs meet IEC,IPC,DIN,MIN standard, behaves ISO-9001 quality system ,UL and Rohs certificate.
Fast lead time and competitive price with high quality are our advantages. PCB lead time is within 10days,
and most can be within 7days. We also established a prototype team to develop customer’s prototype needs.
prototype lead time often can be within 3days.
More information about PCB, pls contact with us!
