9005/HB3 50W 6ohm LED Fog Light No Error LED Load Resistor Wiring Harness

9005/HB3 50W 6ohm LED Fog Light No Error LED Load Resistor Wiring Harness

What is the specification about LED Load Resistor from ADT?                                                                       ADT

1.Product name: 50W LED relay cable
2. Voltage: 9-16V
3. Wattage: 50W
4. Special Features : LED decoder
5. Model No.: LED resistor harness for 9005/HB3 fog lamps
6. Specification: 50W 6Ohm
7. LED type: 9005/HB3
8. LED relay cable 9005 socket 50W 6ohm led resistor.

What is the feature of LED Load Resistors from ADT?                                                                                   ADT

1. It works as warning canceller, decoder, capacitor, or blinker rapid Flash Equalizer to ensure no error message for LED Light or Xenon HID Lighting to install on Headlight (high or low beam) / Fog Light / Daytime Running Light DRL lamp with 9005 housing adapter

2. It will overcome the problem of OBC Warning Error code, excessive flashing or bulb rejection; since standard LED light and Xenon HID light may not work properly on European and latest Japanese vehicles with OBC CAN Bus wiring system

3. Easy pre-wired, Plug & Play installation, Do not need modification of stock wires

4. Equips with 50W 6Ohm Load Resistor

5. It works at 12V

6. Socket Type:  1156 1157 3156 3157 7440 7443 H7 H8 9006 H11 H4

How to Connect the LED Load Resistor With Turn/Brake Bulb Light?                                                           ADT

Connect one wire to ground and the other wire to the turn/brake wire. You can use the T taps so you do not have to cut your car's wiring. One Load Resistor is required for each turn signal bulb.

Note: LED Load Resistor will get hot, therefore, please don't mount the LED load resistors on plastic.

HID xenon kit, Car logo door light, Automotive LED bulb, LED Strip, For BMW LED angel eyes, CCFL Angel Eye, LED License Plate Lamp, LED Work Lamp, HID Work Lamp, LED Daytime Running Light, Parking Sensor, Plasma Halogen Lamp, Car Alarm, Motorcycle LED Headlight, LED Spot light, Chrome Bulbs, etc

What can do for you?

We specialized in Car Light System for about 10 years. Our products including: HID Kit, Auto LED bulbs, For BMW LED Angel eyes, LED Strip, LED License plate lamp, Plasma halogen bulbs, etc.

Why buy from ADT ?

1: Our one-stop services for automobile lighting solutions and accessories from LED, HID, DRL, Parking sensors and so on.

2: We are the largest automotive lighting supplier in China. There are more than 1,000 products to select from ADT.

3: We are able to provide you 6 new products each month.

4: We are very flexible with your order requirements.

5: All of our LED products are CE approved.

6: We check each item 3 times before shipping.

7: Quick response is always one of our first concerns for you.

1. Q: How many resistors do I need for a pair of LED turn signal light bulbs?

A: General speaking, each LED bulb requires one load resistor. For example, if you install both front and back turn signal lights with LED bulbs, therefore you will need 4 load resistors in total.

2. Q: Shall I use load resistors or LED flasher?

A: LED flasher only works for certain cars, but load resistors will work for all. Unless you know for sure the LED flasher works for your car, we still recommend you using load resistors.

3. Q: My front turn signal light bulbs function for both blinkers and parking lights, do I still need resistors?

A: Yes, you do, and please tap the resistor wires to the blinker + and the ground.

4. Q: Do I need load resistors for brake/tail lights?

A: General speaking, you do not need load resistors for brake lights or tail lights, unless you are experiencing the LED bulbs causing error message on dashboard.

5. Q: Where shall I mount the resistor?

A: Since the load resistors will generate a lot of heat, therefore, please mount the load resistor on the metal.
