Product Details
| Condition | New | Place of Origin | China | |
| Brand Name | WM plasma cutter | Model Number | CT312 | |
| Input Voltage | 230v | Rated Current | 19 | |
| Power(W) | 4.2 | Dimensions | 371*155*285 | |
| Usage | manufacturing of hardware,decorations,pipeline install,metalplates | Certification | CE and rohs | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Spefication: plasma cutter consumables
Rated Input Voltage(V) | AC 230V±15%(single phases) 50/60HZ |
Rated Input Current(A) | 19 |
Rated Input Capacity(KVA) | 4.2 |
No-load Voltage(V) | 40 |
Efficiency(%) | 85 |
Power Factor | 0.93 |
Protection Class | IP23 |
Insulation Class | B |
Size (mm) | 371*155*285 |
Weight(KG) | 9 |
| TIG | MMA | PLASMA |
Input current(A) | 10.2 | 15.6 | 19. |
Output current(A) | 120 | 110 | 30 |
Current range(A) | 10~120 | 10~110 | 15~30 |
N0-load voltage(V) | 55 | 55 | 220 |
Working voltage(V) | 15 | 25 | 92 |
Duty cycle imax(25℃) | 60% | 60% | 60% |
Duty cycle 100% (25℃) | 90A | 85A | 20A |
Nozzle intermal(mm) |
|
| 1.0 |
Air pressure(Mpa) |
|
| 0.4 |
Gas flow(L/h) | 120~300 |
| 7800 |
Max,cutting thickness(mm) |
|
| 8 |
Quality cutting thickness(mm) |
|
| 5 |
Arc starting | HF vibration | Touch | HF vibration |
Features
·Plasma cutting, TIG MMA functions included
·HF touch arc starting,economical and practical
·Compact,light and portable
Standard
·1pc of 4m SR-17 TIG torch, 1pc of 5m PT-31 plasma torch,1set of 300A Earth clamp+3m*10mm² Cable +KDP16A,1pc KDP-16A,1set of air regulator,1pc 1.6*150mm tungsten electrode for CT312
Optional:
·CT Pakage1:1 set of 300A Electrode holder +3m 16mm² Cable
·Custom-designed luxury case
Specifications
Standard
·Plasma cutting
·O.C&O.H alarm indicator
·Digital display
·TIG
·MMA
·Current knob
·O.C indicator (O.C&O.H alarm)
·Power supply indicator
