Home > Products > Polymer Fuse Cut Out > 24kv Cut Out Fuse
24kv Cut Out Fuse
- Qingdao/Tianjing/Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Shaanxi, China | Brand Name | TID-Tech | |
| Model Number | 24KV Cut Out Fuse | Type | Fuse Cutout |
Product Description
1. We offer 24 months quality Guaratee.
2. We offer 24 hours on line service.
3. We offer Oversea Technical support .
4. We offer tailor made service.
1.Applied Standard:
IEC 62217 IEC 60255 IEC60282
2.Technical Character:
Product Model | Rated Voltage (kV) | Rated Current (A) | Breaking current (kA) | Impulsed Voltage (kV) | Power Frequency withstand voltage (kV) | Creapage Distance (mm) | Weight (kg) | Dimensions (CM) |
TPFC01 | 10 | 100/200 | 10 | 110 | 40 | 380 | 3.5 | 39×36×11 |
TPFC02 | 15 | 100/200 | 10 | 125 | 45 | 450 | 3.9 | 45×38×12 |
TPFC03 | 24 | 100/200 | 8 | 150 | 65 | 620 | 4.5 | 49X35X15 |
TPFC04 | 24 | 100/200 | 8 | 162 | 68 | 700 | 4.7 | 49X35X15 |
TPFC05 | 27 | 100/200 | 6 | 170 | 70 | 780 | 5.2 | 50X35X15 |
TPFC06 | 33 | 100/200 | 6 | 180 | 75 | 800 | 5.5 | 50X35X15 |
3.Material:
Item | Description of parts | Material |
1 | Insulator parts | Polymer Insulator |
2 | Fuse tube parts | epoxy resin with fiber glass winded vulcanized cotton arc extinction tube |
3 | Contacts parts | Copper alloy with silver coating |
4 | Conductor parts | Pure copper |
5 | No conductor metal parts | Stainless Steel |
6 | Spring parts | stainless-steel backup spring for sustained contact pressure |
7 | Thickness of Steel coating | 80-120µm |
