rotor and stator lamination

 The silicon steel can be 0.2mm, 0.5mm or 0.65mm. The outside diameter could be from 18mm to 1250mm of the whole round

lamination or segments. The core length could be any legnth.

 Usually packed in wooden case or iron frame, plastic frame, it's up to customer's demand.

 The shipping could be seaway or air courier or any express.

 We can offer you one  package service by mould designing, prototyping, batch producing.

 We can offer you one  package service by mould designing, prototyping, batch producing.  We can also offer you various kinds of technologies for stacking such as by rivet, weld, buckle, glue or self-interlock. For the stators , we can offer you powder coating, winding or aluminium die casting for rotors as well.

Jiangyin GATOR Precision Mould CO., Ltd is located in Jiangyin city, Jiangsu Province, China.

In the past nearly 15 years of exploring and developing, Jiangyin Gator has accumulated abundant mould and motor laminations making experience, has created a professional skilled and strong innovative team.

Jiangyin Gator has passed the ISO9001:2008, TS16949 and EN15085 International Quality Management System. Some of products are approved by TUV assessment.

The stators and rotors produced by us have applied in the bellow motors:

Wind /Hydraulic Power Generator                       Elevator Traction Motors

Electric Driven Vehicles/hybrid cars          Rail Transit Motors

Permanent Magnet Motor                                      Linear Motor

Servo Motor                                                                 Stepper Motor
