UNDERSLUNG GENSET
- Ningbo/ Shanghai
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | laidong-UNIV | |
| Model Number | 4L22BD | Output Type | AC Three Phase | |
| Speed | 1800 RPM | Frequency | 60 Hz | |
| Rated Power | 16kw/20kva | Rated Voltage | 460V | |
| Rated Current | 25A |
Product Description
UNDERSLUNG GENSET
Manufactured by Zhejiang Universal Machinery Co.,Ltd
Genset Model | 20ESX | ||
SET | Rated power(Kw/kva) | 16/20 | |
Frequency(Hz) | 60 | ||
Pahse | 3 | ||
Voltage(V) | 460 | ||
Current(A) | 25 | ||
Fuel capacity(L) | 82 | ||
Fuel consumption(L/Hour)
| 3.5 | ||
Dimension (mm) | L | 1400 | |
W | 850 | ||
H | 1100 | ||
Weight(kg) | 570 | ||
Noice level for silent type (Db/7m) | 65 | ||
ENGINE | Model | 4L22BD | |
Prime power(kw/kva) | 16/20 | ||
Cylinders | 4 | ||
Bore×stroke(mm) | 85×90 | ||
Intake Method | Natural intake | ||
Displacement(L) | 2.2 | ||
Speed governing | Mechanical governor | ||
Cooling starting method | Water cooling | ||
ALTERNATOR | Model | DG184D | |
Rated power(kw/kva) | 16/22 | ||
Insulation class | H | ||
Alternator enclosure | IP23 | ||
THIS SET COULD BE OPERATED ON 100% OF THE POWER CAPACITY AT ALTITUTE OF 1500M, AMBIENT TEMPERATUR OF 50°C. WE RESERVE THE RIGHT TO EXPLAIN THE TERMS OF THIS SPECIFICATION. | |||
Certificate: SGS,CE,ISO and Soncap,GOST-R ,more options offer
Want more detailed specification or pictures for our mute diesel genset, please contact us
