Water-cooled Diesel Generator
- SHANGHAI/NINGBO
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Isuzu | |
| Model Number | 30ESX | Output Type | AC Three Phase | |
| Speed | 1500RPM/1800RPM | Frequency | 50Hz/60Hz | |
| Rated Power | 25KW/30KVA | Rated Voltage | 230/400V |
Product Description
Specifications
Water cooled type,Nature IntakeMade by ISUZU-China
00971-50-2182374(UAE office) wilson
Genset Model | 30ESX | ||
SET | Rated power(Kw/kva) | 25/30 | |
Frequency(Hz) | 60 | ||
phase | 3 | ||
Voltage(V) | 127/220 | ||
Current(A) | 82 | ||
Fuel capacity(L) | 82 | ||
Fuel consumption(L/Hour)
| 5.8 | ||
Dimension (mm) | L | 1880 | |
W | 800 | ||
H | 1080 | ||
Weight(kg) | 770 | ||
Noise level for silent type (Db/7m) | 65 | ||
ENGINE | Model | 4JB1 | |
Prime power(kw) | 30 | ||
Cylinders | 4 | ||
Bore×stroke(mm) | 93×102 | ||
Intake Method | Natural intake | ||
Displacement(L) | 2.771 | ||
Speed governing | Mechanical governor | ||
Cooling starting method | Water cooling | ||
ALTERNATOR | Model | UNIV | |
Rated power(kw/kva) | 27.5/34.4 | ||
Insulation class | H | ||
Alternator enclosure | IP23 | ||
THIS SET COULD BE OPERATED ON 100% OF THE POWER CAPACITY AT ALTITUTE OF 1500M, AMBIENT TEMPERATUR OF 50°C. WE RESERVE THE RIGHT TO EXPLAIN THE TERMS OF THIS SPECIFICATION. | |||
