5 gallon/3 gallon/20L/12L/6L/4L/5L barrel filling machine

FOB Price

USD $2,000 - $40,000 / Set

1 Set(Min.Order)

Supply Ability 10 Set / Sets per Month
Port shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Beverage
Packaging Type	Barrel	Packaging Material	Metal
Automatic Grade	Automatic	Driven Type	Pneumatic
Power	4KW	Place of Origin	Jiangsu, China
Brand Name	Huasheng	Model Number	QGF

Product Description

Specifications

5 gallon/3 gallon/20L/12L/6L/4L/5L barrel
barrel filling machine
rising-filling-capping function
2000BPH capacity machine

	Machine characters the rinsing main transmmission is by pneumatic action: the cylinder push the gear, then gear drives rinsing main shaft to rotate, the rinsing position move stablely, and the gear structure can ensure the rinsing rightly to bottle mouth center. When rinsing, filling valve goes into the bottle, the filling time is controlled by magnetic valve to ensure the full filling. The filling time is adjustable to meet full filling requirement When filling action is over, the cylinder push the bottle to capping position, the cap cover the bottle mouth, then cap pressed onto the mouth. After cap pressing action finished, bottles are put out it is easy to sample from sterilizing water tank or make the sterilizing water. The stainless steel filtering net protect the impurity matter from water tank In the rinsing tunnel, there is plastic cutting means enclosure to guard the sterilizing water or alkali water from going outside

Machine characters

the rinsing main transmmission is by pneumatic action: the cylinder push the gear, then gear drives rinsing main shaft to rotate, the rinsing position move stablely, and the gear structure can ensure the rinsing rightly to bottle mouth center.

When rinsing, filling valve goes into the bottle, the filling time is controlled by magnetic valve to ensure the full filling. The filling time is adjustable to meet full filling requirement

When filling action is over, the cylinder push the bottle to capping position, the cap cover the bottle mouth, then cap pressed onto the mouth. After cap pressing action finished, bottles are put out

it is easy to sample from sterilizing water tank or make the sterilizing water. The stainless steel filtering net protect the impurity matter from water tank

In the rinsing tunnel, there is plastic cutting means enclosure to guard the sterilizing water or alkali water from going outside

BARREL FILLING MACHINE Product list

Model	QGF-100	QGF-200	QGF-300	QGF-450	QGF-600	QGF-900	QGF-1200
Filling Vavles	1	2	3	4	8	8	8
Bottles Size	5gallon	5gallon	5gallon	5gallon	5gallon	5gallon	5gallon
Bottle Spec(mm)	270×490	270×490	270×490	270×490	270×490	270×490	270×490
Production CapaCITY(BPH)	100	200	300	450	600	900	1200
Pressure Source (Mpa)	0.4-0.6	0.4-0.6	0.4-0.6	0.4-0.6	0.6	0.6	0.6
Gas Consumption(m³/min)	0.37	0.37	0.6	0.8	1	1.5	1.8
Motor Power(kw)	1.38	1.75	3.8	3.8	7.5	9.75	13.5
Voltage (V)	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ
Weight(kg)	680	800	1500	2100	3000	3500	4500
