Home > Products > Oli/paste filling machine > Zhangjiagang Huasheng customized, tailor designed Tomato sauce/ketchup/lubricant/cooking oil/balm/paste filling machine
Zhangjiagang Huasheng customized, tailor designed Tomato sauce/ketchup/lubricant/cooking oil/balm/paste filling machine
- Shanghai
You May Like
-
Zhangjiagang Huasheng customized, tailor designed Tomato sauce/ketchup/lubricant/cooking oil/balm/paste filling machine
-
Automatic Adhesive Piston Filling Machine
-
Automatic High Viscosity Filling Line For Plastic Bottles
-
Full Automatic Viscous Liquid Filling Machine
-
Automatidc Jar Filling Machines Ketchup Filling Machine
-
Automatic Adhesive Filling Machine
Product Details
Condition | New | Application | Beverage, Food | |
Packaging Type | Bottles, Cans | Packaging Material | Glass, Plastic, Wood | |
Automatic Grade | Automatic | Driven Type | Electric | |
Voltage | 380V | Power | by order | |
Place of Origin | Jiangsu, China | Brand Name | Huasheng | |
Model Number | container filler machine | Dimension(L*W*H) | 2500*2000*2400( mm) | |
Weight | 4200kg | Certification | BV CE ISO | |
After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
olivia oil filling machine Technique parameter:
Filling temperature: 3-5degree
Total power: 4.2KW
Conveyor form: air conveyor
Bottle neck-hanging: GERMAN KRONES
Washing: new type pf bottle neck hanging: GERMAN KRONES
Filling: new type of filling valve GERMAN KRONES
Sealing: magnetic capping technique GERMAN KRONES
Touch screen: TAIWAN WENVIEW
Transducer: American EMERSON
Main electric: GERMAN SIEMENS
PLC: JAPAN OMRON
Approach switch: Korea AUTONICS
Light Fiber switch: Korea AUTONICS
Reducer: HANGZHOU JIE BRAND
Motor: shanghai
Pneumatic elements: TAIWAN AIRTAC
Bottle application: glass bottle
Diameter of bottle body: Φ 50mm —Φ 100mm
Height: 150mm -320mm
Maximum of cap: Φ 40mm
Cap application: plastic
Adjustable form: transducer
Power of Cap unscramble: 0.37kw
Pressure of water supplier: >0.06MPa <0.2Mpa
Height of liquid in slot: 1 -2.5m
Air supplier: >0.5MPa
The pressure of compressor in carbonated drinks: 3MPA
Filling machine
Brief introduction:
With over 20 years manufacture and sales experience in machinery line .
We are expecting you cooperate with us.
Technique parameter:
Model: | DCGF18-18-6 | DCGF24-24-8 | DCGF32-32-12 | DCGF40-40-12 | ||
Capacity :500ml | 5000 | 8000 | 12000 | 16000 | ||
Bottle shape: | roud or square | |||||
PET bottle: (mm) | (Bottle Diameter):φ50-.φ110mm (Height):150-340mm | |||||
Cap: | PE srew cap | |||||
Filling precision: | ≤±5mm | |||||
Filling pressure:(Mpa) | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | ||
Rinsing pressure:(Mpa) | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | ||
Filling volume :(L) | 3.5 | 4 | 6 | 8 | ||
Overall size:(mm) | 2450*1800 *2350 | 2780*2200 *2350 | 3600*2650 *2350 | 3800*2950 *2400 | ||
Weight: (kg) | 3500 | 4500 | 5500 | 6500
| ||
|
|
|
|
|
|
|
Huasheng beverage machinery Co., Ltd. was established in 1994, It's a professional manufacturer of liquid food and beverage equipment. They have good experience especially in filling and capping technology.and they provide customized service and turnkey project.They have 300+ users in and out of China, and now 30% order from regular customer. The products scope as below: PET bottle filling machine,Glass bottle filling machine,Capping machine,Bottle washing machine,Water treatment,Oil filling machine/piston filler,Other bottle filling machine,Labeling machine, wrap packing machine,bottle unscrambler,and some drinks production line auxiliary.
Before sales:
the buyer must cooperate with us with patience, and provide us all needed informations, these information is very important, because the final solution based on these informations.
During build:
we will update the manufacturing process and status to buyers, and we will invite buyer come to test the machine when it finished in our factory, if the buyer think it is ok, we will arrange shipping; or we can take the testing video and send to buyer, the purpose is that the buyer?can inspect the machine but without travelling.
After sales:
We will send technicians to buys factory for installation, commissioning, and operator training; Our warranty period is 12 months, in this period, we provide free parts for buyer as well as the necessary technical support.Out of warranty period, we offer free technical support, and the cost price of spare parts
