Home > Products > New Products > H.264 CCTV Onvif P2P 8CH Standalone HVR Recorder for IP/CCTV camera
H.264 CCTV Onvif P2P 8CH Standalone HVR Recorder for IP/CCTV camera
USD $112 - $134.4
/ Piece
1 Piece(Min.Order)
- 100000 Piece / Pieces per Month
- shenzhen
- Credit Card
You May Like
-
Sony CCD,650tvl,dwdr,DNR,OSD cctv 80M IR IP66 Waterproof outdoor digital camera
-
Sony CCD,650tvl,dwdr,DNR,OSD cctv 80M IR IP66 Waterproof ccd security camera
-
Sony CCD,650tvl,dwdr,DNR,OSD cctv 80M IR IP66 Waterproof outdoor long ir range cctv cameras
-
Sony CCD,650tvl,dwdr,DNR,OSD cctv 80M IR IP66 Waterproof outdoor surveillance cheap cctv camera
-
Sony CCD,650tvl,dwdr,DNR,OSD cctv 80M IR IP66 Waterproof outdoor surveillance video camera
-
650tvl,dwdr,DNR,OSD cctv 80M IR IP66 Waterproof outdoor surveillance cctv camera
Product Details
| Place of Origin | Guangdong, China | Brand Name | CCDCAM | |
| Model Number | HVR8320 |
Product Description
H.264 CCTV Onvif P2P 16CH Standalone NVR Recorder
| Model | HVR8320 |
| Support embedded Linux OS Support BNC and IPC Sync Input Support VGA ,HDMI,CVBS Sync video output VGA,HDMI image resolution Max to 1920*1080 Support HD preview, all channels support Main stream Support Zoom function of preview and playback Support event,playback,backup recording ,support picture playback and search Support One-key recording Support fast playback Support P2P Support 4ch 1080P simultaneous playback | |
| System | |
| Main processor | High performance embedded microprocessor |
| Operating system | Embedded LINUX OS |
| Video spec. | |
| Video compression format | H.264 |
| Display Image Resolution | D1@30fps;720P@30fps;960P@30fps; 1080P@30fps |
| Playback Image Resolution | D1@30fps;720P@30fps;960P@30fps; 1080P@30fps |
| Motion Detection | can setup 192(16×12)pcs motion detection area each channeland multi-level sensitivity(1-6 levels adjustable) |
| Privacy Masking | Support |
| Audio spec. | |
| Audio compression format | adpcm, G711 |
| Two-way audio | N/A |
| Recording Mode | |
| Recording Mode | Manual Recording, Motion Detection Recording, Time Recording, Alarm Recording |
| Recording storage | HDD,Network |
| Frame rate | 30 fps NTSC;25fps PAL |
| Recording Playback | Max support 4ch 1080P synchronously playback |
| Backup Mode | Support HDD,USB Flash Disk store & backup |
| Video | |
| Video Input | 16CH BNC, 4CH 1080P IPC |
| Video output | 1ch CVBS(BNC), 1ch VGA and 1ch HDMI |
| Audio | |
| Audio Input | 16ch BNC |
| Audio Output | 1ch |
| Alarm | |
| Alarm Input | 8ch Alarm input |
| Alarm Output | 1ch Alarm Output |
| Other | |
| Network | 1x100Mbps,RJ45 port; |
| RS485 | Standard 485 port,support half-duplex, green terminal port |
| USB | 2 USB 2.0 ports |
| HDD | 4 SATA Ports, support max 3TB HDD |
| Power | DC +12V /5A |
| Power consumption | 16W-20W(not include HDD) |
| Operation temperature | 0℃-+55℃ |
| Operation humidity | 10%-90% |
| Demension | 365mm * 426mm * 65 mm(1.5U hight) |
| Weight | 3.5---4.05KG(not include HDD) |
