Home > Products > New Products > 12ch 1080P cctv full hd hdmi P2P ONVIF nvr
12ch 1080P cctv full hd hdmi P2P ONVIF nvr
USD $140 - $150
/ Piece
1 Piece(Min.Order)
- 15000 Piece / Pieces per Month
- Shenzhen
- Credit Card
You May Like
-
H.264 16CH HDMI 1080P ONVIF Standalone CCTV NVR
-
IP Camera power supply switch 24 RJ45 Port 16CH POE Switch
-
72pcs IR LEDs 60m IR distance Waterproof IR bullet cctv camera
-
H.264 CCTV Onvif P2P 8CH Standalone HVR Recorder for IP/CCTV camera
-
Sony CCD,650tvl,dwdr,DNR,OSD cctv 80M IR IP66 Waterproof outdoor digital camera
-
Sony CCD,650tvl,dwdr,DNR,OSD cctv 80M IR IP66 Waterproof ccd security camera
Product Details
| Place of Origin | Guangdong, China | Brand Name | CCDCAM | |
| Model Number | NVR7216F |
Product Description
cctv full hd hdmi P2P ONVIF nvr onvif
Features
Feature
Ø With H.264 High efficiency Video Compression
Ø With unique time screen in front of the panel, and displays recorder.
Ø Support Iphone, Android
Ø Support 2*USB2.0 for backup, burning, upgrading operation
Ø Support IE browse and CMS software Stronger network service.
Ø Support Chinese, English, Italian, Portuguese, Spanish, French, German ..... 18 languages
Ø With HDMI, Support 1080P high-definition (1920 * 1080P)
Ø With ONVIF protocol, can connect the ONVIF IP camera directly, also can by IE and CMS.
Ø Support P2P cloud functions
| Model | NVR7216F | |||
| Operating system | Embedded LINUX OS | |||
| Video spec. | Video compression format | H.264 | ||
| Display Image Resolution | 720P@30fps;960P@30fps;1080P@30fps | |||
| Playback Image Resolution | 5Mx4ch* 40fps 1080Px9ch* 225fps , 720Px16ch* 400fps | |||
| Motion Detection | can setup 192(16×12)pcs motion detection area eachchanneland multi-level sensitivity(1-6 levels adjustable) | |||
| Privacy Masking | depends on ipc | |||
| Audio spec. | Audio compression format | adpcm | ||
| two-way audio | 1ch | |||
| Recording | Recording Mode | Manual Recording, Motion Detection Recording, Time Recording, Alarm Recording, | ||
| Recording storage | HDD,Network | |||
| Frame rate | 30 fps NTSC;25fps PAL | |||
| Encode ability | Recording 16ch 720P/1080P@30fps; 16ch 5MP@10fps | |||
| Backup Mode | Support HDD,CD-R,USB Flash Disk store & backup | |||
| Video | Network Video Input | 16ch | ||
| Video output | 1ch CVBS(BNC), 1ch VGA and 1ch HDMI | |||
| Audio | Audio Input | 16ch IPC Composite Audio | ||
| Audio Output | 1ch(support two-way audio) | |||
| Alarm | Alarm Input | 16ch Alarm input | ||
| Alarm Output | 4ch Alarm Output | |||
| Other | Network | 1x10/100Mbps,RJ45 port; | ||
| USB | 2 USB 2.0 ports | |||
| HDD | support 4pcs SATA HDD. (MAX 4TB each) | |||
| Power | DC +12V | |||
| power consumption | 20W(not include HDD and PoE) | |||
| Operation temperature | 0℃-+55℃ | |||
| Operation humidity | 10%-90% | |||
| Demension | 365mm * 426mm * 65 mm(1.5U height) | |||
| Weight | 3.5---4.05KG(not include HDD) | |||
packing
Packing
Related Products
| | | |
Application
Product Overviews
Product overviews
Company Information
Company information
Our advantages:
1. Real manufacurer
2. No MOQ ,small order is acceptable.
3. high quality with factory price
4. products with 1 years warranty
5. Profession aftersale service and technicist support
6. Fast delivery, DHL, UPS, Fedex are used
