STCERA Wear Resistant Ceramic Shaft Ceramic Pin Ceramic Plunger
US$ 1 - 1,000
/ Piece
1 Piece(Min. Order)
- SHENZHEN
You May Like
-
STCERA Precision Structure Zirconia Ceramic Shaft
-
STCERA High Temprature Industrial Zro2 Zirconia Ceramic Shaft
-
STCERA Alumina Ceramic Shaft With High Smoothness
-
STCERA High Hardness 99% Alumina Al2o3 Ceramic Spindle
-
STCERA Custom Zirconia Ceramic Plungers And Pistons
-
STCERA High Strong Acid Resistance Zirconia Ceramic Shaft Bearing
Product Details
| Place of Origin | China | Type | Ceramic Parts | |
| Application | Structure Ceramic | |||
| Model Number | Customization | Brand Name | STCERA |
Product Description
Product Description
Ceramic Shaft we produced are widely used in many industries such as semiconductor devices, optical fiber communication, LED, petroleum, metallurgy, electronics, food, medical treatment, aerospace with their excellent performance of abrasion resistance, corrosion resistance, thermostability and etc.
Material Data Sheet
| Properties | Unit | Alumina | Zirconia | ||||
| 96%Al2O3 | 99%Al2O3 | 99.5%Al2O3 | 99.8%Al2O3 | 99.9%Al2O3 | 3Y-TZP | ||
| Colour | - | White | White | Ivory | Ivory | Translucent | white/black |
| Bulk density | g/cc | 3.78 | 3.88 | 3.93 | 3.93 | 3.98 | 6.03 |
| Water Absorption | % | 0 | 0 | 0 | 0 | 0 | 0 |
| Grain size | μm | 5-10 | 2-5 | 2-5 | 2-5 | 2-4 | 0.4 |
| Bending strength | MPa | 380 | 350 | 360 | 380 | 300 | 1000 |
| KIC | MPa.m1/2 | 3~4 | 4 | 3~4 | 3~4 | 3~4 | 5~8 |
| Vickers Hardness | GPa | 13 | 14 | 14.5 | 14.5 | 15 | 13 |
| Young's Modulus of Elasticity | GPa | 360 | 370 | 370 | 380 | 390 | 200 |
| Thermal Conductivity | W/m° K | 24 | 28 | 32 | 32 | 34 | 2 |
| Coefficient of Linear Expansion | 10-6/°C | 6.7 | 7.2 | 7.2 | 7.2 | 7.2 | 10.5 |
| Dielectric Constant (1MHz) | - | 9.1 | 9.5 | 9.6 | 9.6 | 9.9 | 33 |
| Dielectric Loss Angle (1MHz) | - | 0.0002 | 0.0001 | 0.0001 | 0.0001 | 0.0001 | 0.002 |
| Dielectric Strength | V/m | 15×106 | 15×106 | 15×106 | 15×106 | 15×106 | 11×106 |
| Volume Resistivity | Ohm.cm | >1014 | >1014 | >1014 | >1014 | >1014 | 1013 |
| (RT) | |||||||
Shipping
Because of ceramics is easily broken, we all use FEDEX and UPS express our goods, so we can guarantee the safety of the product.
Our Services
Can be customized according to customer’s drawing, sample etc.
