Home > Products > sectional material > 80*80 equal galvanized angle steel bar
80*80 equal galvanized angle steel bar
- Shanghai Tianjin Ningbo
- T/T L/C D/P D/A
You May Like
-
Hot rolled carbon steel bar material galvanized iron 45 degree steel angle bar size
-
Hot dipped galvanized S235 Hot rolled angle steel bar
-
galvanized steel profile steel angle bar
-
ST series galvanized edge angle steel bar
-
black/galvanized hot rolled equal unequal steel angle bar
-
Q195-Q420 Series 7# Hot rolled carbon steel bar construction material galvanized iron
Product Details
Standard | AISI, ASTM, BS, DIN, GB, JIS | Dimensions | 20*16*3mm-200*200*12mm | |
Grade | SS400-SS540 Series | Place of Origin | Shanghai, China | |
Brand Name | Magang;Angang;Baogang | Model Number | S235,S355,Q235,Q345,SS400,ASTM A36 | |
Type | Other, equal or unequal | Application | structural building,Structural;Buliding |
Product Description
the specifications of equal steel angle
Standard Sectional Dimension (mm) Leg Size*Leg Size*thickness | Weight kg/m | Standard Sectional Dimension (mm) Leg Size*Leg Size*thickness | Weight kg/m |
25*25*3 | 1.12 | 90*90*7 | 9.59 |
30*30*3 | 1.36 | 90*90*10 | 13.3 |
40*40*3 | 1.83 | 90*90*13 | 17.0 |
40*40*5 | 2.95 | 100*100*7 | 10.7 |
45*45*4 | 2.74 | 100*100*10 | 14.9 |
45*45*5 | 3.38 | 100*100*13 | 19.1 |
50*50*4 | 3.06 | 120*120*8 | 14.7 |
50*50*6 | 4.43 | 130*130*9 | 17.9 |
60*60*4 | 3.68 | 130*130*12 | 23.4 |
60*60*5 | 4.55 | 130*130*15 | 28.8 |
60*60*6 | 5.37 | 150*150*12 | 27.3 |
65*65*6 | 5.91 | 150*150*15 | 33.6 |
65*65*8 | 7.66 | 150*150*19 | 41.9 |
70*70*6 | 6.38 | 175*175*12 | 31.8 |
75*75*6 | 6.85 | 175*175*15 | 39.4 |
75*75*9 | 9.96 | 200*200*15 | 45.3 |
75*75*12 | 13.0 | 200*200*20 | 59.7 |
80*80*6 | 7.32 | 200*200*25 | 73.6 |
80*80*7 | 8.48 | 250*250*25 | 93.77 |
90*90*6 | 8.28 | 250*250*35 | 128.0 |
The company is now the Shougang and Hanbao million tons boiler container plate East China general agent, Wugang, Wuhan steel varieties agreement households, Jinan steel, Laiwu Steel, Nanjing Steel agent at the same time, the new steel, Maanshan Iron and steel, Xiangtan Steel, Rizhao, several major steel mills Jinxi etc. products. The company products are the implementation of IS0900 quality management system, passed into the EU CE certification, for materials according to national standard, European standard EN, American Standard ASTM / ASME, Japanese Standard JIS standard production, customers can be more assured more satisfied with the use of my company a variety of materials.
our company in different packaging products are in accordance with national requirements of qualified packaging, some even are steel, channel steel packing and so on, the company relies on Shanghai port to the advantage of strong, extremely and nearly 10 Shanghai several international freight agency cooperation, go by sea transport. Individual samples, belonging to the customer urgent products, the company adopts air transport. Customer requirements is our steps to success. Customer satisfaction is our greatest comfort.
our company is located in the Yangtze River Delta area, the main wholesale, retail stainless steel, die steel, tool steel, spring steel, aluminum alloy, copper alloy, titanium alloy and other metal materials; Suzhou gold Yibai metallic material limited company products in the industry enjoy a higher status, the company with the a number of manufacturers and agents to establish a long-term stable relations of cooperation. The famous brand has: Japan Hitachi metal "Hitachi HITACHI" special steel, Japan steel "Datong Datong special steel; DAIDO" UDDEHOLM "ASSAB of Sweden Assab tool steel;" German "Derringer DILLINGER" high-speed tool steel. The German "BUDERUS BUDERUS" "die steel; South Korea Doosan DOOSAN" tool steel, Japan fujikoshi "NACHI high speed tool steel;" Japanese "high frequency KOSHUHA" special steel; Japan "Nippon NIPPON" plastic mould steel; American "Kenna KENNA" tungsten steel; USA "Fang Cola" Japan "Fuji FUJILLOY tungsten steel;" Austria "Bai Lu Taiwan" BOHLER "tool steel; steel" special metal material. After growing and rapid development of the company scale, become the most professional mould steel; metal materials suppliers, strength, heavy credit, abiding by contract, guarantee product quality, with many varieties of management features and the principle of small profits, won the trust of our customers. Companies adhering to the "good governance, innovation and strong" spirit and, strict, fine, solid, and new management philosophy, honesty, return the first business philosophy, and constantly promote the reform and development, and actively fulfill their social responsibilities, and strive to create a safe production, resource conservation and environmental protection enterprise, facing the new situation of economic and international the competitive environment, gold Yibai company will continue to innovate and strive to create, with customers to create a "common vision of first-class quality, environmental protection and energy saving", with the scientific development concept, good development results, advanced corporate culture to achieve sound and rapid development of enterprises.
