12mm christmas led string lights rgb dmx flat ws2801 chip
USD $0.1 - $0.35
/ Piece
50 Pieces(Min.Order)
- 10000 Piece / Pieces per Month
- Shenzhen port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| LED Light Source | Epistar Smd5050 LED | Input Voltage(V) | DC5V | |
| Lamp Power | 0.3 | Lamp Luminous Flux(lm) | R16/G32/B13 | |
| Lamp Luminous Efficiency(lm/w) | 18 | Color Temperature(CCT) | Other, RGB | |
| Working Temperature(℃) | -40, +60 | Working Lifetime(Hour) | 50000 | |
| Lamp Body Material | Plastic | IP Rating | IP65 | |
| Certification | CE | Emitting Color | Changeable | |
| Place of Origin | Guangdong, China | Brand Name | SOYA LED | |
| Model Number | SY-C12-WS2801 |
Product Description
12mm christmas led string lights rgb dmx flat ws2801 chip
Specification
Products Name | 12mm LED string lights WS2801 Square |
Model NO. | SY-C12-WS2801 |
Power Consumption | 0.3W |
Work Voltage | DC5V |
Beam Angle | ≥120 |
LED Quantity | 1pcs |
Color | Magic color/colorful/changable |
Dimension | 26*18*23mm |
Waterproof Grade | IP65 |
Work Temperature | -40-60°C |
Life-span | 50,000H |
Certificate | CE&RoHS |
Warranty | 2 years |
You'll see arrows on the PCB board to show you input to output(power and singal)
The 12mm string lights can be work with SD card controller(t1000s,t200k,t4000 and t8000),or dmx controller.
RGB Pixels are digitally-controllable lights you can set to any color, or animate. Each RGB LED and controller chip is molded into a 'dot' of silicone. The dots are weatherproof and rugged. There are four flanges molded in so that you can 'push' them into a 12mm drill hole in any material up to 1.5mm/0.06" thick. They're typically used to make outdoor signs. These pixels are round, but we also have some with a flat square back. It affects mostly the way the wires lie and the colour of the wires!
The pixels are connected by a 4-conductor cable. +5V (Red), Ground (Yellow), Data (Green) and Clock (Blue). Data is shifted down from one pixel to the next so that you can easily cut the strand or attach more onto the end.
Each dot is digitally controlled, with an internal 8-bit PWM LED driver (24-bit color for 16 million different shades). The pixels must be clocked by a microcontroller, we have an example code linked below that works on an Arduino, it should be simple to adapt it to any other microcontroller.
The pixels use 8mm diffused RGB LEDs, with a 120 degree beam width. The total max brightness of all LEDs is about 1600mcd but with the light more evenly distributed & mixed than a clear LED. (Please note: mcd ratings of LEDs are notoriously inflated by most LED sellers, so be extra-skeptical when reviewing LED ratings!)
Sold by the strand, each strand has 50 pixels in series! Each strand has two JST SM 4-pin connectors(non-waterproof) so you can connect multiple strands in a row, as many as you wish, just watch for how much current they want. We now have LED pixel strands with the power wires (Red & Yellow) spliced out so its really easy to connect 5VDC.
You can drive these with an Arduino using any two microcontroller digital pins, check this library which also has example code to demonstrate the strands and be sure to read Adafruit's detailed tutorial on usage!
The pixels are connected by a 4-conductor cable. +5V (Red), Ground (Yellow), Data (Green) and Clock (Blue). Data is shifted down from one pixel to the next so that you can easily cut the strand or attach more onto the end.
Each dot is digitally controlled, with an internal 8-bit PWM LED driver (24-bit color for 16 million different shades). The pixels must be clocked by a microcontroller, we have an example code linked below that works on an Arduino, it should be simple to adapt it to any other microcontroller.
The pixels use 8mm diffused RGB LEDs, with a 120 degree beam width. The total max brightness of all LEDs is about 1600mcd but with the light more evenly distributed & mixed than a clear LED. (Please note: mcd ratings of LEDs are notoriously inflated by most LED sellers, so be extra-skeptical when reviewing LED ratings!)
Sold by the strand, each strand has 50 pixels in series! Each strand has two JST SM 4-pin connectors(non-waterproof) so you can connect multiple strands in a row, as many as you wish, just watch for how much current they want. We now have LED pixel strands with the power wires (Red & Yellow) spliced out so its really easy to connect 5VDC.
You can drive these with an Arduino using any two microcontroller digital pins, check this library which also has example code to demonstrate the strands and be sure to read Adafruit's detailed tutorial on usage!
You can also download the FastSPI library and our Chaser.ino sketch. Connect the Data wire (Blue) to Pin 11 and Clock (Green) to Pin 13 as well as Power and Ground
- 12mm diameter (0.45") 75mm deep (1.5")
- 80mm / 3" apart between each pixel
- 50 pieces per string
- These pixels use a WS2801 chip for full 24 bit color
- 5V power, 60mA maximum per pixel (LED on full white)
- Maximum current required 3A per string
- 2-pin SPI-like protocol
- Brightness: Red = 3.3 Lumens/300 mcd, Green = 10 Lumens/1000 mcd, Blue = 2.7 Lumens/300 mcd (mcd calculation based on full 120 degree beam)
