Pre-heated Integrative Solar Water Heater
- shanghai or ningbo
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | JNIP | |
| Model Number | JNIP-1 | Type | Pressurized | |
| Application | Solar Thermal | Pipe Material | Other, glass and copper |
Product Description
Solar hot water heater system
------------------------------Why Jineng Solar----------------------
Primary competitive advantages:
1) CE, Solar Keymark, CCC, ISO certificed.
2) High quality, competetive price, prompt delivery.
3) Satisfied after-sale service.
4) Environmental Protection.
5) Export experience to 49 countries.
6) OEM accepted.
Features:
1) The vacuum tube adopts the three-layer heat collection techniques: higher heat-getting efficiency, reducing the water-stagnation
2) It can withstand the pressure from tap water (0.6Mpa)
3) The best angle: a reasonable bracket angle basing on different latitude in order
to gain more heat
4) Convenient installment: available on both horizontal and slanting house roofs
Super and strong heat preservation: using the world's advanced hydraulic pressure
technology to make it with higher heat preservation
5) The diffuse flat plate reflector: to increase heat-getting efficiency
6) Meeting the demand of all kinds of families
7) Huge aperture area and water capacity
8) Assistant tank: adding water into the water tank automatically
Working Principle
Vacuum tube absorbs solar energy and transfer heat into the tank,but the water in the tank is not used and the tank is just as a storage tank. One copper coil is installed in the tank as the heat exchanger. When water flows into the copper coil, it absorbs the heat of water in the tank via copper coil.This will enable you to enjoy inatant hot water.
| Jineng Pre-heated Solar Water Heater | |
| Innertank | SUS304 or 316(315mm/360mm) |
| Outer tank | 0.4mm painted steel/stainless steel420mm/460mm |
| Frame | 1.5mm galvanized steel/stainless steel/aluminum alloy |
| Collector | 58×1800mm/47×1500mm general tube/three-high tube |
| Insulation layer | 50mm-60mm polyurethane foaming |
| Angle | 27/30/45 |
| Assistant tank | 5L/8L/12L/50L/60L etc |
| Capacity | 200L-360L |
| Copper coil | with 30m copper coil inside tank |
| Pressure bearing | 0.6Mpa |
| Absorbtance | >94% |
| Heat preservation | 72h |
| Tube quantity | 20-36 tubes |
