Newest and Best Heat Efficiency Solar Collector

 Newest and Best Heat Efficiency Solar Collector

   Model:JNSC-M series

1) Working Principle:

2. Specification and technical data:

1) 20mm/24mm nikel-plated heat pipe header
2) Thick insulation layer: 60mm rock wool
3) With mirror between two tube walls

4) Copper manifold: diameter 38mm / thickness 0.8mm

5) Headbox and frame: 2.0mm aluminum alloy

6) Lowest test temperature: -50 degrees

7) One special plate to protect tube holders ( could be)

8) Test pressure: 6 bar

9) Heat preservation: 72 hrs

10)Hail resistance: 25mm

3. Features:

1. M series heat pipe solar collector applies vacuum tubes with mirror inside, and 20mm/24mm nickel-plated heat pipe header is also used. Meanwhile, thick insulation later, 60mm rock wool, is adopted to supply better insulation property.
2. Heat pipe with mirror inside as a new type of heat pipe, its inner and outer diameters are 37mm and 58mm, respectively. The mirror inside improved the absorbance effect of solar energy, and higher heat efficiency is achieved.
3. M series solar collectors makes better use of reflectors than that of reflectors on the frame; and easier installation (the installtion way is eactly same as collector without reflectors on frame).
4. Newly designed manifold with artistic appearance is equipped.

      4. Technical Information:

5.Service:

1. We offer customers 5 years for whole solar systems;
2. Carton design for customs is free offered when goods sent by container
3. When you have any questions regarding our products, feel free to contact us. We will be very glad to service for you.
4. 1% extra vacuum tubes, slicone rings will be sent for free.

6 More details show:

  JINENG is a professional M series heat pipe solar collector manufacturer based in China. We offer a broad range of products, including U-pipe solar collector, split solar water heating system, compact integrated solar water heaters, and more.
