IP65 Waterproof 12V RGB LED Strip Light

Specifications

IP65 Waterproof 12V RGB LED Strip Light

Aluminum case, nice and wide application, less power consumption, high shining or flicker while dimmer.

Suitable for photograph, camera, and TV station as well.

Specifications:

*Input Voltage: DC12V
*LED Strip Light QTY: SMD5050 RGB chip, 30 or 48 LEDs per meter
*Power watt: 3-8W per meter
*RGB LED Strip Light Size:
IP33, 5000x12X2mm
IP55 with sillicon tube: 5000x13X4mm
*Every 10CM or 3 chips per cutting along with cutting mark.
*Every 3 LEDs works with one IC
*114 different color changing effects
*Beam angle: 120 degree
* RGB LED Strip Light  Body material: Flexible white FPC with strong 3M double faced adhesive tape on the back for easy installation.
*End cap: Covering with 10CM length black and red wire
*Ra: 85
*Power facter: 90
* Environment condition: -20 to 60 Celsius
* Environment humidity: 10%-90%
* Life span: 50000 hours
*IP Grade: IP33, IP55
*CE, RoHS compliant
*OEM&ODM service are available.

LED Strip Light Packing detail:
*5m packing, Anti-Static Bags with dring agent,
*250m/carton, non water proof G. W: 8kgs; IP55: G. W: 14kgs,
Carton size: 71*22*20 CM.
*Brown or white carton, 5 layer paper, color box design on request.

New LED Digital Strip Light Feature:
*The LED Strip Light is used for the building outline, more convenient for decorating exterior wall.
*Excellent replacement for tradional RGB digital tube light or guardrail tube light, more advantage in waterproof performance, installation and stability.
*Special control system, it can be changed variety effects at any time.
*The latest technology support, maximum connecting 20M when used in a DC series circuit.

LED Strip Light Series:
*12V /24V LED Strip Light SMD3528 light source, 30 / 60 / 120 / 144 LEDs per meter
*12V /24V LED Strip Light SMD5050 light source, 30 / 60 / 120 LEDs per meter
*12V /24V RGB LED Strip Light SMD5050 light source, 30 / 60 LEDs per meter
*12V digital RGB LED Strip Light SMD5050 light source, 30 / 48 LEDs per meter

*220V LED Strip Light SMD3528 light source, 60 / 120 / 144 LEDs per meter
*220V LED Strip Light SMD5050 light source, 60 LEDs per meter
*220V Digital LED Strip Light SMD3528 light source, 48 LEDs, chasing, flash, twinkle, slow fade etc.

LED Strip Light Application: - Cove l ighting - Architectural lights for canopy, corridor, window, archway - Backlight or edge lighting for signage - DIY l ights for home use - Path and contour marking - Decorative lights for holiday, event, show, exhibition
-Edge-lighting of transparent or diffused materials
-Illuminated signs
-Mood lighting
-Stairway accent lighting
-Channel letter lighting

LED Strip Light Attention:
Attention:
*LED strip light Storage Temperature: -40 to +80 Celsius
*Operating Temperature: -25 to +60 Celsius
*Installation surface must be smooth, clean and dry.
*The part of LED components can not be fixed on the surface of the sharp edge.
*LED Strip light should not be collided or crushed.
*LED Strip light can be cut following the cutting lines.
*LED strip light must not exceed 5 meters, when used in a DC series circuit.

Shipping information

Dimension: 1000*12mm/1pcs

Packing: 1000*12mm/1pcs

Net weight: 0.2kgs

Gross weight: 0.25kgs
