RGB LED sign wireless and usb programmable rolling information P3 indoor led display screen

LED Lamp Specification of P3 LED Video Wall

1

LED  Chip  Brand

Red   Opto  /  Epistar
Green  &   Yellow:   Silan

2

Wave  Length  (nm)

R   625nm;
G   525nm;
B   470nm

3

Pixel  Configuration

SMD 3 in 1

Module & Cabinet  Specification of P3 LED Video Wall

4

Physics  Distance  Between  Pixels

3  mm

5

Physics  Pixel  Density

111,111 Pixel/m²

6

Module  Dimensions  (W  x  H)

192mm x 192mm

7

Physics  Pixel  /  Module

64 x 64 = 4096

8

Cabinet  Dimensions  (  W  x  H  xT)

960mm x 960mm x 120mm

9

Physics  Pixel  /  Cabinet

320 x 320 = 102, 400

10

Cabinet  Weight

37kg

11

Cabinet  Material

Steel Cabinet / Aluminum Cabinet

12

Cabinet  Frame

Standard Frame
Simple Frame (without backdoor)
Lifting Frame (specially for rental use)

Screen Specification of P3 LED Video Wall

13

Dimention

Customized Size

15

Viewing  Distance  (min,   max)

>3m

16

Power  Consumption  /  Screen

MAX 800 w/m²
Average 240 w/m²

17

Drive  Mode

1/16 scan

18

Refresh  Rate

300-3000 HZ adjustable

19

Frame  Rate

60HZ

20

Display  Flatness

0.5mm

21

Maintenance

Back maintenance, replace the module

22

Led  Life  Span

100, 000 hours

23

Supply  Voltage

AC220V/50HZ, ± 10%;
AC110V/60HZ, ± 10%

24

Operating  Temperature

-50º C~+50º C

25

Operating  Humidity

10%-90%

26

Storage  Temperature

-50º C~+60º C

27

Viewing  Angle

Horizontal 120°, Vertical 120°

28

Grey  Scale

Red, green, blue each 16k

29

Display  Colors

4096 Billion

30

IP  Rating

IP20

31

Aging  Time  in  Factory

More than 72 hours constantly

Control System of P3 LED Video Wall

32

The  Software

LED Studio

33

System  Supported

Win  98  /  2000  /  2003  /  XP / WIN7

34

Control  Mode

Synchronous or Asynchronous

35

Display  Capability

Flash,   Video,   Graphic,   Text

36

Signal  Supported

RGB,   VGA,   DVI,   etc.
