Advertising P10 Full Color HD Viedo Arc Led Display

Specifications

Advertising P10 full color HD viedo arc led display

1. arc p10 outdoor advertising led display screen module size:160mm*160mm

2. Brightness:7000cd/sqm

3. Pixel density:10000dots/sqm

4. Average Power:185w/sqm

5. IP rate: IP67 full waterproof

6. Design life:100000hours

Feature and Advantage

1.High brightness Contrast:4000:1, which is a very high level to ensure a vivid image of our LED display screen system

2. First-class LED chip: Supplied by Cree & other high strictly selected LED chip to ensure the long lift-time and high brightness of our LED display screen system

3.Clear vivid image quality even in direct, full-on sunlight to ensure you attracts more audience to get short ROIof  your LED display screen's investment.

4.Long-term Brightness:More 7000-nit brightness(for outdoor full color)(2000 nits brightness for indoor full color)capacity throughout product lifetime of the LED display screen.

5.Easy Installation & Using: easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system

6.Convenient Servicing: Front and rear cabinet access make the maintance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.

Our service

1.Your inquiry related to our products or price will be replied in 24hrs

2.OEM&ODM,any your customized lightings we can help you to design and put into product

3.Distributoership are offered for your unique design and some our current models

4.Protection of your sales area,ideas of design and all your private information

5.Top Quality+Reasonable Price+Responsible After Service=Successful & Win

6. Export countries :  Peru,  Mexico, Colombia, Turkey, US, UK, etc.

Trade Terms

1.Payment: T/T 30% as deposits before production, T/T 70% balance before delivery

2.Shipping freight are quoted under your requests

3.Shipping port: Shenzhen, Mainland China

4.MOQ:1sqm  p10 outdoor led display

5.Delivery time: 10 days after receive pre-payment

LED Screen Parameter

1. Brightness: ≥7000cd/sqm (outdoor)
2.Viewing Angle: 120°
3.Driver Mode: 1/4 constant current
4. Working Temp:-20°C~+60°C
5. Working Hum: 10%~90% RH
6. Microchip: Red 9 from OPTOTECH, green and blue 10*12 from Silan
7. Diameter of leds: 3mm
8. Pixel pitch: 10mm
9. Voltage : AC100~240V
10. Power Consumption: Max 20W--40W
11. Control mode: RS232, RS485 serial port, remote, U disk and wireless.
12.Material of Frame: Black iron
13. LED Moving Sign Composing Parts: LED display, software, data line and adapter

14.Multi language: English/Chinese/Greek...
15. Support bmp, jpeg, gif picture format, even gif animation display
16.Manual and automatic adjusts brightness by time period.
17. Manual/automatic powered on and off.
18. Self-contained clock and spare battery not paused once powered off.
19.Can extend temperature and hygrometer display (need extra charge)
20. Computer operation request: WIN XP or VISTA, WIN 7

High quality LED lamps material

High quality led connectors &  LED Control system diagram

LED display certificates

Working factory:

Applications:
