Focus Industry Pig Weaner Crate Farrowing Crates for Pigs Piglet Weaner Crates for Sale

Farrowing rate/set(2400*1800mm)

Item

Name

unit

quantity

note

1

FRP Support beam

m

2.6

H=100mm.

2

fix support for beam

piece

2

wearing plastic support,PP material,high hardness

3

sow iron floor

piece

4

600*700,the leak floor,QT450 ball mill cast iron,No edges and smooth surface

4

piglet plastic floor(10%  leak)

piece

2

600*700mm 10%leak,the pig heat preservation zone,signle reinforcement bearing 225kgs,PP material

   5

piglet leak plastic floor

piece

2

600*700,the leak floor,signle reinforcement bearing 225kgs,PP material.

6

piglet leak plastic floor

piece

4

600*400  the leak floor,signle reinforcement bearing 225kgs,PP material.

7

the sow guardrail

set

1

main material 1Tsun pipe,thick 2.5.with adjustable bracket and compressive bar, can adjust length, after welding forming integral hot-dip zinc.

8

piglet coaming

m

5

30*250 plug-in type;UV resistance element content≥5‰,anti-aging,anti-UV.PVC content≥75%.

9

piglet coaming fixing parts

set

1

Includes a variety of columns, u-shaped groove, a fixed plate etc.

10

lampshade& fix parts

set

1

lampshade& fix parts,

11

sow feeder

piece

1

The polypropylene material,304 stainless steel resistant to bite.

12

piglet feeder

piece

1

circular 304 stainless steel material.

13

galvanized steel beam for sow

piece

2

H=100mm,Steel plate stamping integral hot-dip zinc after welding.

14

galvanized steel flat beam for sow

piece

3

connect two steel beam.

15

sow drink pipe

set

1

Galvanized water pipe L=800mm,(including clips,water injection well choke)

16

piglet water bowl

piece

1

304 stainless steel stretched forming at a time(including water injection well choke)

17

install attachment

set

1

expansion bolts & all kinds of screw

weaner crates pen/set(2100*3600mm)for 10 piglets

Item

Name

unit

quantity

note

1

 weaner crates

set

1

1.8mthick

2

 longitudinal beam

piece

7

Steel plate stamping integral hot-dip zinc after welding.

3

 cross beam

piece

4

Steel plate stamping integral hot-dip zinc after welding.

4

support leg

piece

6

Steel plate stamping integral hot-dip zinc after welding.

5

red plastic plate

piece

18

60x70

6

double sided feeder

piece

1

six holes
